Original HBA-072915CNC MPG Manual Pulse Generator MPG Pendant for Euchner Fits System for Fagor
Features:
- One selector switch and 6 positions (X, Y, Z, 0, 4, 5)
- Depending on the type, there are 100 or 25 square wave pulses per revolution on the output of the handwheel
- Phase difference output allows additionally connected controls to identify the direction of movement
- The pulse recognition processing is carried out in the control device
- Wear-free magnetic detent mechanism
- It is for Fagor system
Technical Data:
- Pulses/revolution: 2x25 or 2x100
- Calibration position: 100
- Housing material: aluminum
- Weight (without adjustment wheel): 95g
- Magnetic detent mechanism: 0.04 to 0.06Nm
- Maximum axial load: 25N
- Maximum radial load: 40N
- Operating temperature: 0 to 50°C
- Storage temperature: -20 to 50°C
- Maximum air humidity: 80% (condensation is not allowed)
- Protection class: IP65
Package Included:
- 1 x CNC MPG
