PM-602 One-to-Two 612.5-667.25MHz U-band Professional Wireless Transmitter and Receiver for Conference Microphones

PM-602 One-to-Two 612.5-667.25MHz U-band Professional Wireless Transmitter and Receiver for Conference Microphones

Description:
- Professional wireless transmission, wired microphone to wireless audio transmission system suitable for 48V phantom powered wired microphones, conference microphones, interview microphones, etc. Effective transmission distance of 60-100 meters, U-band wireless transmission, strong anti-interference ability, and can be received through partition walls.
- Suitable for various scenarios, compatible with 98% wired capacitors and dynamic microphones on the market, providing stable power output (3V~48V).
- Effective receiving distance of 100 meters, stable and strong anti-interference performance. Equipped with RDS wireless digital pilot function, each transmitter has a different random identity code, effectively solving interference and cross frequency phenomena.
- Powerful cruising time, it is powered by dual AA batteries (not included) and can work continuously for 7 hours with real-time battery level display, ensuring stable use.

Key Features:
- Compatible with all wired microphones
- With 48V power supply
- U-band wireless transmission
- 100 meters effective receiving distance
- Excellent anti-interference ability
- Long duration

Transmitter Parameters:
- Frequency range: 612.5 - 667.25MHz
- Receiving method: superheterodyne secondary frequency conversion
- Adjustable channel number: 200 channels
- Channel interval: 250kHz
- Adjacent channel rejection: ≥70dB
- Mirror frequency rejection: ≥80B
- Oscillation mode: PLL frequency synthesis
- Frequency stability: ±10ppm
- Receiving sensitivity: -100dBm to -68dBm adjustable
- Frequency response: 40 - 1800Hz
- Comprehensive SNR: ≥110dB
- Comprehensive distortion: ≤0.1%
- Audio output: 500mV (6.35mm mixed output, XLR balanced output)
- Output impedance: 200ohms for XLR interface; 1Kohms for 1/4 interface
- Power supply: DC12V/1A

Receiver Parameters:
- Frequency range: 612.5 - 667.25MHz
- Adjustable channel number: 200 channels
- Channel interval: 250kHz
- Oscillation mode: PLL frequency synthesis
- Frequency stability: ±10ppm
- Modulation method: FM modulation
- Harmonic rejection: ≥70dB
- Maximum modulation degree: 75k
- RF power: 10 - 30mW
- Frequency response: 40 - 1800Hz
- Distortion: ≤0.1%
- Function display method: LCD
- Built-in battery specification: 2x1.5V AA battery (not included)
- Duration: 8 - 20 hours

Package Included:
- 2 x Transmitters
- 1 x Receiver
