1575.42MHz GNSS Signal Repeater Amplifier Timing GPS Low Noise Antenna Amplifier Support for Beidou/GPS

1575.42MHz GNSS Signal Repeater Amplifier Timing GPS Low Noise Antenna Amplifier Support for Beidou/GPS

Specification:
- Centre frequency: 1575.42MHz for GPS; 1561MHz for BD2
- Current: ≤25mA
- Gain: ≥25dB
- Noise ratio: ≤3dB
- Gain flatness: ≤2dB
- Interference suppression: 25dB±100MHz
- Power supply: 3 - 5V DC
- Size: 128 x 36 x 32mm
- Net weight: 200g
- Connector: SMA
- Working temperature: -45℃ ~ +85℃
- Storage temperature: -50℃ ~ +90℃
- Relative humidity: 100%

Package Included:
- 1 x Signal Amplifier
