CX-50S High Voltage DC Power Supply Without Shell Constant Voltage For Air Purifier Fresh Air System

CX-50S High Voltage DC Power Supply Without Shell Constant Voltage For Air Purifier Fresh Air System

Features:
- New CV high voltage power supply
- Designed with no shell
- With four holes for installation
- With spark protection and short-circuit protection
- Can work without load
- With external indicator light (12V)
- With output current analog value output port, which can be used for external indicator (voltmeter)
- Dimensions: 130 x 72 x 40mm (LxWxH)
- Can be used in fresh air systems, air purifiers, medical sterilization equipment, etc.

Specifications:
- Model: CX-50S
- Input voltage: AC 180V~250V(50Hz)
- Input current: 0-1A
- Output voltage: DC 6KV-12KV (Adjust constant voltage through a blue potentiometer. Output voltage can be automatically adjusted according to load.)
- Output current: DC 0-3mA

Package Included:
- 1 x High Voltage Power Supply
