DC-1000MHz RF Wide Band High Isolation Power Divider 433M One to Two Low Insertion Loss Power Splitter

DC-1000MHz RF Wide Band High Isolation Power Divider 433M One to Two Low Insertion Loss Power Splitter

Description:
- A power divider is a device that divides the energy of one input signal into two or more equal or unequal outputs, or in turn combines the energy of multiple signals into one output, which can also be called a combiner.
- The module casing is a CNC casing with excellent conductivity and shielding performance.

Specification:
- Performance: one to two equal power
- Working frequency: DC-1000 MHz
- Typical insertion loss: 0.5dB
- Typical isolation degree of branch ports: > 20dB
- Maximum bearing power: 1W
- Input and output impedance: 50ohm
- Interface: SMA female connector

Package Included:
- 1 x Power Divider

Actual Measurement Parameter:
Loss of input port to output port:


Output isolation degree:
