Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
---|---|---|---|---|---|
Price /Unit | $20.80 | $20.37 | $19.73 | $18.89 | Contact US |
PS-LF-4 RF Power Divider 10K-1.5G RF Power Splitter 1 IN 4 OUT Radio Frequency Low Frequency
Specifications:
- Model: PS-LF-4
- Frequency range: 3dB bandwidth, 10k-1.5G; 1dB bandwidth: 10k-900M
- Insertion loss: about 7.5dB
- Output port isolation: 20dB: 1M-700M; 10dB: 0.1M-1000M
- Allowable power: 25dBm
- Port impedance: 50 ohms
- Interface: SMA
- Others: terminal block DC, withstand voltage 25V
- Size: 70 x 45 x 18.5mm/2.8 x 1.8 x 0.7" (LxWxH)
- Weight: 60g/0.13 lb
Package Included:
- 1 x Power Divider
