SCD41 Purple Gas Sensor Module for Carbon Dioxide Detection Temperature and Humidity in One IIC Communication

SCD41 Purple Gas Sensor Module for Carbon Dioxide Detection Temperature and Humidity in One IIC Communication

Description:
- Carbon dioxide is a key indicator of indoor air quality that impairs human cognitive ability and happiness. SCD40/SCD41 is the next generation of miniature carbon dioxide sensor for Sensirion. SCD40/SCD41 has high accuracy and high cost performance. The module leads out the power supply and communication pins with 2.54mm spacing pin interface. On-chip temperature and humidity compensation realizes humidity and temperature measurement through built-in temperature and humidity sensor. SCD40/SCD41 can realize intelligent adjustment of indoor ventilation system based on carbon dioxide concentration, and indoor air quality helps to maintain a healthy and efficient environment under low carbon dioxide concentration for a period of time.
- More details: https://pan.baidu.com/s/1rQHWomhnol4oHt18B_VZ-g  password: 067t

Features:
- Reference accuracy specified range:400-2000 ppm for SCD40; 400-5000 ppm for SD41
- Power supply voltage range: 2.4 – 5.5 V
- High accuracy: ± (40 ppm+5%)
- Digital I2C interface
- Integrated temperature and humidity sensor
- Low power operation to < 0.4mA average at 5V, 1 meas./ 5 minutes
- Module size: 13.4 x 21.6mm

Parameter:
- Carbon dioxide measuring precision: ± (50 ppm+5%MV)
- Measuring range: 400-5000ppm
- Accuracy: ±40ppm
- Relative humidity measuring range: 0-95%RH
- Typical relative humidity precision: 6% RH

Interface definition:
- GND: Power negative input
- VDD: Power positive input
- SCL: IIC Clock interface
- SDA: IIC Data interface

Package Included:
- 1 x SCD41 Gas Sensor Module
