TAP1 PRO Standard Version 4PCS 627BP Op Amps Fully Balanced Portable HiFi Headphone Amplifier Electronic Tube Amplifier

TAP1 PRO Standard Version 4PCS 627BP Op Amps Fully Balanced Portable HiFi Headphone Amplifier Electronic Tube Amplifier

Features:
- The electronic tube has second-generation shock absorption technology and is flexibly connected to the PCB board.
- The component architecture of desktop computers is integrated into a small body to achieve HIEND level enjoyment without occupying space. Combined with PSU power supply (optional), it can reach the level of a desktop computer.
- Four channel fully balanced architecture design, supports upgrading to fully discrete Class A, supports single ended upgrade to fully balanced (3.5 output upgrades to 4.4 fully balanced).
- The sunken pin socket technology optimizes the operational amplifier space within a thinner body.
- Supports 4.4 balanced and 3.5 single ended input, 4.4 balanced and 3.5 balanced output, support 3.5 upgrade to full balance with stronger sound quality.
- Function: Supports 10DB high gain and high thrust, supports turning off the electronic tube to use pure transistor mode, and supports electronic tube attenuation.
- Support power connection: PSU-2 (optional); After connecting to the power supply, it can achieve desktop level thrust, and connecting to PSU2 power supply can increase the current thrust output by about twice.

Specification:
- USB charging support: 18W
- Duration: about 9 hours
- THD+N: about 0.0003% (turn off the electric tube); about 0.002 (USB)
- L+R maximum output power: 2000mW (10ohms), 6000mW (+ PSU-2)
- Supported headphone impedance: 5 - 600ohms
- Battery capacity: 5000mAH
- Supported frequency: 5 - 80K
- Product size: 13 x 7 x 2.7cm
- Net weight: about 300g

Precaution:
- When replacing the op-amp, please pay attention to the orientation of the op amp. If it is installed in the wrong direction, it will cause damage to the op amp itself.

Package Included:
- 1 x Headphone Amplifier
