Tarot 650 Sport Quadcopter TL65S01 with Naza V2(GPS) & Tarot 4114 320KV Motor & 30A ESC & Propeller for FPV Photography

Availability: In stock, usually dispatched in 1 business day

  • Price:$666.60
  • Price in reward points: 6666 Reward Points: 67
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $653.27 $639.94 $619.94 $593.27 Contact US
Quantity:

Tarot 650 Sport Quadcopter TL65S01 with Naza V2(GPS) & Tarot 4114 320KV Motor & 30A ESC & Propeller for FPV Photography









Tarot 650 Sport Description:
- Tarot 650 sport quadcopter is the upgrade version of 650 series
- Standard configuration includes electronic folding landing gear, landing gear controller TL8X002, lower gravity center, more stable large installation space, attracting appearance
- The quacopter is with PCB circuit of high strength, easier and safer for wiring power supply or ESC, providing enough space for other flight control system
- The new motor base is added space for brushless ESC, wires protection size, clip design for adjusting motor level
- Tarot  650 sport quadcopter is specially designed for customers of high demands, suitable for minitoring, remote sensing, detecting drawing, farm monitoring and so on
- Net weight: 0.75kg
- Total weight: 1kg

Tarot 4114 320KV Motor Descriptions:
- Tarot TL100B08-01 is used for Tarot Series aircraft or Tarot Quadcopter
- Manufactured by: Tarot
- KV:320KV
- Stator diameter: 41mm
- Stator end thickness: 14mm
- Number of stator end: 24
- Motor pole number: 22
- Motor essential resistance: 126mΩ
- Wire diameter: 0.31mm
- Current without load: 0.5A
- Axis diameter: 4mm
- Body length: 32mm
- Overall length: 37mm
- Outer diameter: 46mm
- Weight: 148g

DJI Nava V2 with GPS Descrioption:
- DJI has continued improving the Naza Flight Controller, the latest is the Naza M V2 which is the next exciting product to the market with the latest technology being integrated in to the new NAZA M V2. The basic functionality will remain the same as DJI NAZA V1, however there are a few new features.
- The main controller hardware structure has been optimized and the expandability and performance of the flight control system has been enhanced further with new attitude stabilization algorithms, these provide better flight performance / manoeuvrability and a new level of flight control performance which provides a better flight experience; (flight control is smoother, take-off is easier). The Naza M V2 has support for OctoCopter and has the added safety feature on HexaCopter and OctoCopter should a motor stop working it can still be landed safely.
- The Naza M V2 has automatic course deviation compensation, this reduces the effects of magnetic disturbance and interference around the compass, there is a warning on detection of magnetic disturbance. The IMU advanced calibration; error identification and warning reduce the impact of sensor errors in flight so increasing the overall performance.
- The GPS unit added to the Naza M V2 will see great position holding and RTL features for additional safety. The V2 NAZA with the GPS unit will have IOC to help new and experienced pilots gain the most from their systems with easy orientation assistance while flying at greater distances.

Package List:
- 1  x  Tarot 650 Sport Quadcopter TL65S01 Frame Kit with Electronic Folding Landing Gear
- 1  x  DJI NAZA-M V2 Flight Controller with GPS
- 4  x  Tarot 4114 320KV Motor for Multicopter
- 4  x  Hobbywing Platinum 30A ESC 2-6S (SKU:25094)   ( or 4  X  Hobbywing XRotor 40A OPTO Brushless ESC 2-6S (SKU:32304) )
- 2 pairs  x  15" 1555 Carbon Fiber Propeller  (SKU:27033)
