ToneMax Vimi I 2x70W Hifi Stereo Amplifier Power Amp Desktop Power Amplifier for Study Living Room

ToneMax Vimi I 2x70W Hifi Stereo Amplifier Power Amp Desktop Power Amplifier for Study Living Room

Description:
Vimi I is a small hifi power amplifier. It can be used in bedrooms, studies, cafes and small living rooms. The sophisticated and compact appearance makes it easier to integrate into the home environment.

Features:
* 2x70W high power audio amplifier
* 0.5dB HI-END level volume controller
* 12dB active active preamplification
* Touching musical performance, interpreting melodious and delicate movements
* 4X analog inputs
* Silver contact relay switching input: Small contact resistance reaches mΩ level. No bandwidth loss. Crosstalk is minimal. Purely mechanical, without dynamic problems
* CS3310 resistive attenuated volume control and 0.5dB high precision volume
* Dual single-channel design, without inter-channel interference. Independent power supply for left and right channels. Stereo gold-plated RCA input and oxygen-free copper speaker output terminals. Completely separated backstage power amplification. 4CH RCA stereo inputs and virtually unmeasurable zero-distortion lines. The dual single-channel architecture is for higher crosstalk
* Original paired transistor 2SC5198/2A1941 for Toshiba. The voice is sweet. The vocals are natural and delicate, transparent and ethereal. The overall tone is stunning. And the overtones are rich and clear
* Class AB offset working state
* Fully symmetrical double differential zero-distortion circuit design
* High-power toroidal transformer and high-capacity filter capacitors
* Perfect protection circuit and relay control output
* EU standard standby function
* Full-function remote control: with an infrared remote control
* With power-off memory, over-voltage and over-current protection
* Aluminum alloy power supply button
* Exquisite craftsmanship and well-made
* 0.5dB precision control–Crystal volume controller CS3310. The control accuracy is 0.5dB per step. Graded volume control system, gain attenuation of the front-end resistance matrix, post-amplification of trans-conductive gain control and dual-voltage balanced power supply. At low volumes, it maintains a high signal-to-noise ratio. Less distortion for small signals
* Taiwan AV-Explorer oxygen-free copper terminals: Precision CNC machining. The body is made of oxygen-free copper. 24K gold plating and extremely low connection resistance. Signaling is fast
* Transformer uses pure copper wires to ensure abundant power. The mid-transformer design cleverly uses a radiator to shield the transformer magnetic field. The left and right channels are independently powered to eliminate crosstalk
* Fully symmetrical architecture design: The interior layout is full, well-organized, and the functions are concise and straightforward
* Aluminum alloy matte panel is stylish and concise: The panel is made of pure aluminum alloy, and it is engraved by a CNC machine tool. It is 10mm/0.4" in thickness. The panel is equipped with volume and standby buttons. Aluminum alloy buttons make it easy to operate. High-end VFD screen displays rich content. It is clear and bright

Product Details:
* Basic specifications: 2x70W zero distortion power amplifier
* Line architecture: Dual single-channel architecture, completely separated power amplification
* Transistor: Imported transistors for Toshiba
* Input: 4-channel stereo input
* Volume control: CS3310 0.5dB trans-conducting volume controller
* Remote control: Full-function remote control
* Display: Full dot matrix VFD display

Product Parameters:
* Rated voltage: 220V
* Rated output power: ≥70W
* Input sensitivity: 200mV
* Frequency response: 10Hz-50KHz±1dB
* Maximum residual noise: ≤ 500uV (at maximum volume position)
* Signal-to-noise ratio: ≥ 88dB (wideband, unweighted)
* Channel crosstalk: ≥ 86dB (wideband, unweighted)
* Maximum input level: ≥ 3800mV
* Harmonic distortion: ≤ 0.001% (1KHz 1W)
* Phase distortion: ≤ 0.01 degree (20Hz-20KHz)
* Standby power consumption: ≤ 1W (CE standard)
* Dimensions: 210 x 60 x 240mm/8.3 x 2.4 x 9.4" (LxHxD)
* Weight: 4kg/8.8lb
* G.W.: 5.5kg/12.1lb

Package Included:
* 1 x Power amp
* 1 x Product quality certificate
* 1 x User manual
* 1 x Power cable
* 1 x Remote control
