TYT Walkie Talkie FM Radio DMR Transceiver VHF UHF Radio 136-175Mhz 400-480Mhz 1000CH MD-380

TYT Walkie Talkie FM Radio DMR Transceiver VHF UHF Radio 136-175Mhz 400-480Mhz 1000CH MD-380

Features:
- Frequency band: VHF 136-175Mhz; UHF: 400-480MHz
- Large Capacity Battey with 2200mAh:
- Continuous use for about 2 hours; Normal use for about 9-12 hours; Standby time  for about 150 hours
- IP67 waterproof function: can stay for about 30 minutes 1m underwater
- 1000 channels
- Remote kill/stun/activate
- Voice prompt
- Power-on protection
- Color LCD display
- Text messages in digital mode
- Encryption function
- Built-in CTCSS/DCS
- Up to 1000 channels
- Priority scan
- Compatible with Mototrbo Tier I&II
- DTMF decoding and encoding
- Updated software available for new features
- Private call, group call, all call in digital mode.
- Operate in both Digital&Analogue mode, allows easily migrate from analogy to digital
- Provide clearer voice communications in digital mode, throughout the coveerage area.

Specification:
- Model: MD-380
- Frequency Range: VHF 136-175Mhz; UHF: 400-480MHz
- Channel: 1000 Channels
- Channel Spacing: 12.5KHz
- Operating Voltage: 7.4V
- Battery Type: Li-ion
- Operating Temperature: -30+60
- Store Temperature: -40+85
- Antenna Impedence: 50OHm
- Audio Output Power:  ≤1000mW
- Battery Capacity: 2200mAh standard Li-ion Battery
- Dimemsion (H*W*D): 131*61*36*(Not Including Antenna)
- Weight: 258g

Transmitter:
- Output Power: High: ≤5W (HI)   Low: ≤1W (Low)
- Frequency Stability: ±1.0PPM
- Adjacent Channel Power: ≤-60dB
- Free Time Slot Power: TDMA: ≤57dBm
- Hum and Noise: -40dB 12.5KHz
- Spurious Radiation: Antenna: 9KHz-1GHz  ≤-36dBm;1GHz-12.75GHz    ≤-30dBm
- FM Modulation Mode: 12.5KHz: 11K0F3E
- 4FSK Digital Mode: 12.5KHz(data ony): 7K60FXD;12.5KHz(data + voice): 7K60FXE
- Modulation Maximum Deviation: 2.5JHz 12.5KHZ
- Nonactive Slot Power: -57dBm

Receiver:
- Analog Sensibility: 0.35uV/ -116dBm(20dB SINDA); 0.22uv/ -120dBm (Type)
- Digital Sensibility:  0.3uV/ -117.4dBm(BER 5%);0.22uV/ -110dBm(BER 1%)
- Co-channel Rejection: ≥-12dB
- Rated Audio Power: 1W
- Rated: Audio Distoration: 3%(Type)

Tips: Please choose express delivery because the package includes battery.

Package list:
- 1 x TYT MD-380 Digital Mobile Radio (DMR)
- 2x Antenna
- 1 x Li-ion Battery 2000mAh
- 1 x Belt Clip
- 1 x Charger
- 1 x Adapter
- 1 x User Manual
- 1 x Programming Cable
