0.2uf 1200V Capacitor for Motor Metallized Polypropylene Film Capacitor 10-Pack
Features:
- Small dissipation factor
- long life,safety
- small size small loss
- ISO 9001:2008 standard
- With a small loss,anti-moist,excellent electrical performance,reliability,large capacity,long life and good self-healing properties
Application:
- AppIied to starting and better working of single-phase motor in 50Hz(60Hz) AC electric power system. It is widely used for electric fan, range hood, air exchange fan,washing machine, and also power saver
Technical parameters:
|
Capacitance Range |
0.1μF—35μF |
|
Capacitance Tolerance |
±5% , ±10% |
|
Rated Alternate Voltage |
250VAC, 350AC, 370AC, 400VAC, 440VAC, 450VAC,500VAC |
|
Rated Frequency |
50/60 Hz |
|
Dissipation Factors |
≤0.002(1KHz,20°C) |
|
Operating Temp. |
-40°C ~ +85°C or -40°C ~ +70°C |
|
Case Material |
PBT, PP, ABS, Flammability Class - UL 94 V -2, 750C (RTI) |
|
Dielectric |
Polypropylene with self healing SH |
|
Insulation Resistance |
≥3000S |
|
Weather Category |
40/85/21, 40/70/21 |
|
Withstand voltage(Terminal to Terminal) |
2 X Rated Voltage |
|
Withstand voltage (Terminal to Case) |
Minimum 2000 V AC for 1 Min. |
|
Ref. Standard |
IEC - 252-1993 |
|
Quality System |
ISO 9001:2008 |
|
Approvals |
CQC,CE |
|
Application |
Electrical motor, pump, washing machine, Power saver |
|
Capacitance Range |
0.1μF—35μF |
|
Capacitance Tolerance |
±5% , ±10% |
|
Rated Alternate Voltage |
250VAC, 350AC, 370AC, 400VAC, 440VAC, 450VAC,500VAC |
|
Rated Frequency |
50/60 Hz |
|
Dissipation Factors |
≤0.002(1KHz,20°C) |
|
Operating Temp. |
-40°C ~ +85°C or -40°C ~ +70°C |
|
Case Material |
PBT, PP, ABS, Flammability Class - UL 94 V -2, 750C (RTI) |
|
Dielectric |
Polypropylene with self healing SH |
|
Insulation Resistance |
≥3000S |
|
Weather Category |
40/85/21, 40/70/21 |
|
Withstand voltage(Terminal to Terminal) |
2 X Rated Voltage |
|
Withstand voltage (Terminal to Case) |
Minimum 2000 V AC for 1 Min. |
|
Ref. Standard |
IEC - 252-1993 |
|
Quality System |
ISO 9001:2008 |
|
Approvals |
CQC,CE |
|
Application |
Electrical motor, pump, washing machine, Power saver |
