4K SDI Video Encoder H.265 H.264 Encoder Ultra Low Latency Audio Video Output HDMI SDI VGA XD3S

4K SDI Video Encoder H.265 H.264 Encoder Ultra Low Latency Audio Video Output HDMI SDI VGA XD3S

Advantages:
- SDI HD decoder
- Ultra low latency, support 1080P@60
- H.265 4K decoding
- Output 1-way SDI, 1-way VGA, 1-way HDMI
- 4 channels video, 1 channel audio. For TS/FLV/RTSP/RTMP/Multicast
- Delay of docking with encoder 80-200 ms
- Decode RTSP address of ONVIF protocol device
- Decode 4 channels and output 4 pictures at the same time
- H.265/H.264 video decoding

Features:
- H.265 4K decoder
- Decode 4 channels of video and 1 channel of audio. 2160P@30
- Ultra-low latency: Independently developed efficient and low-latency media transmission protocol. Encoder-decoder docking. Minimum 80-260MS.
- Four pictures: 4 channels of video and 1 channel of audio can be output.
- Decode multiple video streams: For HTTP TS video stream; For HTTP FLV video stream; For RTSP video stream; For RTMP video stream; multicast video stream; Output through SDI/VGA/HDMI interface.

Specifications:
Media access:
- Standard protocol: For RTSP/HTTP TS/HTTP FLV/RTMP/UDP
- Private protocol: For HTTP PTE

Video decoding:
- Type: H.265/H.264
- Frame rate: 1-60
- Bit rate (kbit): 32-32000
- Resolution: maximum support 2160P@30
- Number of channels: 1 to 4 channels

Audio decoding:
- Type: G711A/G711U/AAC+/AAC++/MP2/MP3
- Number of channels: single channel/dual channel
- Sampling rate Hz: 8000/11250/22500/44100/48000
- Number of channels: 1-way

Video output:
- HDMI: 2160P@30/1440P@30/1080P@60/1080I@60/1080P@50/1080I@50/1080P@30/1080P@25/720P@60/720P@50/576P@50/480P@60
- VGA: 2160P@30/1440P@30/1080P@60/1080I@60/1080P@50/1080I@50/1080P@30/1080P@25/720P@60/720P@50/576P@50/480P@60
- SDI: 2160P@30/1440P@30/1080P@60/1080I@60/1080P@50/1080I@50/1080P@30/1080P@25/720P@60/720P@50/576P@50/480P@60
- Color: Brightness, contrast, chroma, saturation, adjustable

Audio output:
- HDMI: 48KHz dual channel output
- 3.5MM: dual channel output
- Enable: enable/disable

General:
- Network: Gigabit
- Configuration management: configuration management via WEB
- Power supply: 12V/DC, 2A
- Power consumption: <5W
- Working temperature: -20℃ to 60℃
- Working humidity: <90%, non-condension
- Product Size: 15.5 x 10.2 x 3.2 cm

Package Included:
- 1 x Set of Video Encoder
