80V 10000uf Electrolytic Capacitor 110*40*40mm
Features:
- long life cycle capacitor
- eco-capacitor
- high power density
- short charging time
Specfictions:
|
Item |
Characteristics |
|
Operating temperature range (°C) |
-25°C~+85°C |
|
Rated voltage range (V) |
80V |
|
Capacitance tolerance (%) |
±20%(20°C,120Hz) |
|
Leakage current |
I: less than 0.02CV or 5Ma (Whichever is smaller) (Five Minutes) |
|
I: Leakage Current (uA), C: Rated Capacitance (uF), V: Working Voltage(V) |
|
|
Temperature characteristics |
Electrostatic Capacity Charge: C (-25°C)/C(+20°C) more than 0.7(120Hz) |
|
Endurance (+85°C) |
After 2000 hour application of WV at +85°C with the capacitors shall meet the following limits: |
|
Capacitance Change: Within±20% of the initial value |
|
|
Dissipation factor(Tan õ ): Less than 200% of the Initial specified value |
|
|
Leakage Current: Less than the initial specified value |
|
|
Shelf life (+85°C) |
The capacitors are restored to 20°Cafter exposing them at 85°C 500 hours without voltage applied, Satisfies characteristic W of JIS C514. It shall meet the following Limits; |
|
Capacitance Charge: Within±20 of the initial value |
|
|
Dissipation factor(Tan õ): Less than initial specified value |
|
|
Leakage Current: Less than the initial specified value |
