86x118 Two Phases Stepper Motor with encoder 5A 8.5N/mHigh Speed Providing High Quality and Good Performance

Availability: Out Of Stock

  • Price:$148.04
  • Price in reward points: 1480 Reward Points: 15
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $145.08 $142.12 $137.68 $131.76 Contact US
Quantity:

86x118 Two Phases Stepper Motor with encoder 5A 8.5N/mHigh Speed Providing High Quality and Good Performance

Description:
- The stepper motor with encoder is to help the user of stepper motor (real time compensation) closed loop controller to convenient operation.There are two-phase 400 wire, 500 wire or 1000 wire encoder, through the closed loop controller software 4 frequency can reach at 1600, 2000 or 4000 pulses per turn.
- The motor is a high-speed motor of high-quality, the raw material is better than the general motor, high speed well performance, small noise and vibration.
- The limit speed can reach 3000rpm, 1200rmp can enable engraving machine or CNC milling motion to work stably.
- Base: 86 x 86
- Length: 118 (shaft not calculated)
- Phase resistance: 0.7R
- Current: 4.2A
- Maximum torque: 2N/m
- Shaft diameter: 14mm  Length: 20
- Weight: 3.8KG
- Mounting hole:  5.5 x 4
- Center distance: 69.6 x 69.6.
- The positioning flange front cover: 73 x 1.5 height
- The encoder (shield) length: 2 meters (length can be adjusted according to demand), and add a signal amplifying circuit, to improve signal stem interference capacity and transmission distance.
