AC 110/220V to DC 12V LED Light Strip Power Supply Power Supply Adapter Transformer 12V 10A 120W

Availability: In stock, usually dispatched in 1 business day

  • Price:$16.59
  • Price in reward points: 166 Reward Points: 2
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $16.26 $15.93 $15.43 $14.77 Contact US
Quantity:

AC 110/220V to DC 12V LED Light Strip Power Supply Power Supply Adapter Transformer 12V 10A 120W

Features:

- Full voltage input
- Multiple Protections: Short-circuit, overload, and over-voltage protections
- 100% full-load aging test
- Built-in EMI filter
- Average working time over 50,000 hours
- Compact size

Specifications:
- Input Voltage: AC 110/220V±15% (Switched via switch)
- Input Frequency: 47 to 63Hz
- Input Start Surge Current: 5A/115V, 30A/230V (Cold Start)
- Output Adjustable Voltage Range: ±20% (Rated Output Voltage)
- Overload Protection: 105% to 150% (Rated Load), Self-Recovery
- Over-voltage Protection: 115% to 135% (Rated Output Voltage)
- Short-Circuit Protection: Self-Recovery
- Output Start Time: ≤2S@120VAC; ≤1S@230VAC
- Output Duration Time: ≥10mS@120VAC; ≥20mS@230VAC
- Working Environment: -20℃ to 55℃, 20% to 93%RH (Without Silver Frost)
- Storage Environment: -40℃ to 85℃, 10% to 95% RH
- Cooling Way: Built-in Cooling Fan
- Safety Standard: In line with GB4943, UL60950-1, EN60950-1
- EMC Standard: According to GB9254, EN55022 CLASS A
- Withstand Voltage Test:
  I/P-O/P: 1500V AC/1min
  I/P-FG: 1500V AC/1min
  O/P-FG: 500V AC /1min
- Power Consumption: 120W
- Dimensions: 188 x 47 x 38mm

Package Included:
- 1 x LED Light Strip Power Supply
