ALL to SDI Scaler Converter CVBS VGA DVI HDMI to HD-SDI 3G-SDI Signal Converter HDV-SA01
User manaual: Click here
Introduction
The ALL to SDI Scaler Converter allows you to upscale Composite,VGA,DVI,HDMI signals to high definition video of SDI formats (HD-SDI SMPTE 292M or 3G-SDI 424M/425M), then output to both ports at the same time.
Features
- Support HDMI, DVI, VGA and Composite Video input signals;
- Support two SDI output simultaneously;
- Support SDI output distance up to 100 meters (3G-SDI), or 200 meters (HD-SDI);
- Scales any input signal to the HD-SDI or 3G-SDI output signals;
- Support HDMI input timings: VGA@60 ~ SXGA@60 & 480i ~1080p@60 Hz;
- Support VGA/DVI input timings: VGA@60 ~1920×1080@60 Hz;
- Support Composite Video input timings NTSC, PAL,SECAM;
- Support Black screen signal output;
Package Contents
- ALL to SDI Scaler Converter 1pcs
- 12V/2.5A DC power adaptor 1pcs
- Operation Manual 1pcs
