Description:
- Support the LORA radio frequency transmission
- Function modularization design of RF external circuit
- Battery-powered
- Can be installed on the ceiling
Specifications:
1.Master Parameter
- CPU: ARM-Cotex M3 kernel; Basic Frequency-32MHz; 32bit
- Memory: 128KB, Flash/16KB, RAM/4KB, EEPROM
2.Hardware Parameter
- Sensor: Built-in Photoelectric Smoke Sensor
- Indicator Lights: LED
- Built-in LoRa Antenna
3.Radio Performance Parameters
- Data Transmission Rate: 300bps~5.4bps
- Operating Frequency:470MHz~510MHz/863MHz~870MHz/902MHz~928MHz
- Support LORAWAN & P2P
- Maximum Power: 17dBm
- Sensitivity:-140dBm
4.Battery Capacity: 3V
5.Working Condition:
- Temperature: -10℃~+55℃
- Humidity: 10%~90%
6.Characteristics of DC
- Supply Voltage: DC3V
- Sleep Current: 2uA
- Operating Current: 110mA
7.Dimension: 110 x 60mm
