DUALSKY XM4005TE-13 690KV Outrunner Brushless Disk Type Motor for Multi-rotor
Specfications:
- Model: XM4005TE-13
- KV: 690RPM/V
- Weight: 53g
- Diameter: 40mm
- Length: 20mm
- Diameter of Shaft: 3.175mm
- Mounting holes pitch: 16/19mm
- Slots,Poles: 24, 28
- Idle Current(Io) @10V: 0.6A
- Resistance(Ri): 176mOhm
- Cruising power[8 mins]: 113.39W
- Bursts current[15s]: 13.93A
- Peak power[15s]: 206.17W
- Recommended ESC: XC1812BA
- Setup 1 (No. of Cell, Prop.): 3S, 12x5
- Setup 2 (No. of Cell, Prop.): 4S, 8x5
- Max. weight of 4-rotor copter: 1.13kg
- Max. weight of 3D models: 0.38kg
- Memo: 1KG 4-rotor copters, 400 class airplanes
Application: specially designed for quadcopter and multi-rotor aircrafts
