EPEVER WiFi 2.4G RJ45 D WiFi Adapter 5V DC for EPsolar MPPT Solar Charge Controller with RJ45 Connector

Availability: In stock, usually dispatched in 1 business day

  • Price:$24.31
  • Price in reward points: 243 Reward Points: 2
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $23.82 $23.34 $22.61 $21.64 Contact US
Quantity:

EPEVER WiFi 2.4G RJ45 D WiFi Adapter 5V DC for EPsolar MPPT Solar Charge Controller with RJ45 Connector

Description:

- Through a local 2.4G WiFi network, the EPEVER WiFi 2.4G RJ45 D can transmit all operational data from the EPEVER solar controller, inverter, or inverter/charger to the EPEVER cloud server in real time. Users can remotely monitor the connected devices and program parameters via the EPEVER server platform and mobile APP.

Features:
- Applicable to EPEVER controllers, inverters, or inverter/charger with RJ45 port
- Use immediately after connecting easy and convenient operation
- Directly powered by the communication port
- Up to 20 meters of communication distance
- Support the Local monitoring and "EPEVER Cloud" working mode

Specification:
- Model: EPEVER WiFi 2.4G RJ45 D
- Working voltage: 5V±0.5V (Powered by RS485 com. port)
- Power consumption: Peak emission: 150mA; Idle: 310uA
- Enclosure: IP30
- Communication method: RS485
- Communication parameters: 115200Bps, 8N1
- Interface standard: EPEVER communication standard V1-1.0
- Work frequency: 2.4~2.4835GHz
- Work temperature range: -40℃~85℃
- Dimension: 63 x 19 x 10mm
- Net weight: 7.7g

Package Included:
- 1 x WiFi Adapter

Note:
- The WiFi adapter working voltage is 4.5V~5.5V and peak emission is 150mA, which is only suitable for devices that meet this requirement.
