Descriptions:
- FX1N-24MT 32-Bit PLC Board 12-In 12-Out For Driving Magnetic Valve
- 1.Appearance Size:122*87*42mm
- 2.Installation Hole Size:115*80mm
- 3.Input high-speed pulse C235,C251 functions are compatible with FX1N
- 4.Y0 Y1 most trigger 10K pulse,its function is compatible with FX1N
- 5.Output port is collector open circuit,rated current is 5A;and it can directly drive DC magnetic
- valve and do not need any external relays
- 6.With a RS232 port,and it can be used for downloading ladder diagram or various of touch
screen and text screen communications
Basic Sequential Control
- Instructions:LD,LDI,OUT,AND,ANI,OR,ORI,LDP,LDF,ANDP,ANDF,ORP,ORF,ORB,ANB,MPOUT,RST,NOP,END,CALL,CJ,FENDSRET,STL,RET
- Data Process Instructions:ZRST,DECO,ENCO
- High-Speed Process Instructions:SPD,PLSY,PWM,PLSR,HSCS,HSCR
- Location Instructions:PLSV,DRVI,DRVA
- Convenience Instructions:ALT,INCD
- Contactor Comparison Instructions:LD+,LD>,LD<,LD<>,LD<=,LD>=,AND=,AND>,AND<,AND<>,AND<=,AND>=,OR=,OR>,OR<,OR<>.OR<=,OR>=
- All instructions support 32 bit instructions and trigger instructions
