| Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
|---|---|---|---|---|---|
| Price /Unit | $25.24 | $24.72 | $23.95 | $22.92 | Contact US |
Description:
- Use high-quality materials, crossover points, component values, process production, routing, scientific simulation and physical school sound.
- Can match most speakers
- 4Ω/8Ω 10 inch or less 3-way speaker can be used
Specification:
- Impedance: 4Ω-8Ω
- Rated power: 150-200W
- Crossover point: treble 3.5Khz (-18DB)
Midrange 800hz-3.5Khz (-18DB)
Bass 800hz (-12DB)
- Size: 145*95mm
- Weight: 0.3kg
Correct layout
Since the frequency divider is composed of multiple inductors. The treble bass inductors will sense each other, and the coupling effect like a transformer will cause intermodulation interference, which seriously affects the sound quality. Separate the two inductors and shift the coupling path by 90 degrees from each other. This layout can reduce the distortion to a small extent.
Circuit parameter
