HZK PZ2511 20Ω/200Ω/2kΩ/20kΩ DC Resistance Meter High-Precision Milliohm Meter with 3½-digit Display
Features:
* DC Low-Resistance Tester
* Stable Performance
* High Accuracy
* Strong Anti-Interference
* High Measurement Speed
* High Measurement Precision
* Kelvin Four-Terminal Measurement
* Built-in Reference Resistor
* Low-Current Measurement
* Wide Applications: Relay Contact Resistance, Connector Contact Resistance, Motor Coils, Various Resistance Alloy Wires, and Wire Resistance
Specifications:
* Model: PZ2511 (Standard)
* Measurement Range: 20Ω/200Ω/2kΩ/20kΩ
* Resolution: 0.01Ω/0.1Ω/0.001kΩ/0.01kΩ
* Display Type: 3½-digit digital display
* Current Measurement Range: 100mA/10mA/1mA/0.1mA
* Accuracy: ±(0.1% full scale + 2 digits)
* Open-Circuit Voltage: < 4.5V
* Measurement Update Rate: Approx. 6 times/second
* Operating Environment: 5-40°C, 20%–80% RH (non-condensing)
* Operating Voltage & Power Consumption: 220V±10%, 50/60Hz; optional wide voltage 86-265V
* Accessories: 4-terminal Kelvin clip test leads
Packing List:
* 1 × Main Unit
* 1 × Pair of Test Leads
* 1 × Power Cable
* 1 × Certificate of Conformity
* 1 × Warranty Card
* 1 × User Manual
Packaging Details:
* Weight: 3kg
