WYDZ-PE42412 RF Switch Module 10MHz-8GHz Single-Pole 12-Throw High Isolation RF Switch with STM32 Main Control Board

Specifications:
- Model: WYDZ-PE42412
- Frequency range: 10MHz - 8GHz
- Input and output interface: SMA gold-plated female connector
- Power supply: XH2.54-2PIN-5V power supply
- Control port: V1-V2-V3-V4-LS
- Main control board: STM32F103
- Module size: 7 x 8cm
- Net weight: 100g (with STM32 main control)

Communication Protocol:
(1) TTL serial communication: baud rate 9600. Channel protocol control: "CH-01"; Modify the corresponding values based on the number of channels selected, and be sure to add a return.
(2) USB virtual serial communication: No baud rate required. Channel protocol control: "CH-01"; Modify the corresponding values based on the number of channels selected, and be sure to add a return.

Application:
- 5G/4G base station, micro base station: multi band RF channel switching, antenna diversity.
- Software defined radio SDR/broadband receiver: filter bank, multi-channel signal routing.
- RF testing equipment: multi port automatic testing, signal switching.
- WiFi 6E/7, CPE, vehicle communication: multi band front-end switching.
- Satellite communication and radar: multi channel transceiver switching within C-band.

Packing List (Depending on Selected Configuration):
Without STM32 Control Board
- 1 x RF Switch Module

With STM32 Control Board
- 1 x RF Switch Module
- 1 x STM32 Main Control Board
- 1 x Type-C Cable
