CSR8675 Decoder Bluetooth 5.0 APTX HD LDAC AAC SBC Decode For hifi Amplifier Audio

This listing is for the decoder that without USB, this model with CSR8675 Chip,if you need the other two version,please contact us

Specifications:
- Digital input:
- Bluetooth: LDAC/aptxX HD/aptX/AAC/SBC
- USB: (USB input function is only available with USB version)
 - Optional version: XMOS version: PCM 44. lKHz-384KHz/32Bit
                         DSD DSD64/128/256 (DOP/Native DSD)

- Optional version: ARM+CPLD version: PCM 44. lKHz-384KHz/32Bit
                                  DSD DSD64/128/256/512 (DOP/Native DSD)
- Analog output:
- RCA output: 2. 4Vrms/-0dB
- 3.5mm headphone : 2. 4Vrms/-0dB

(The earphone holder is directly connected to the RCA holder and can be connected to most of the earphones. For better drive quality, it is recommended to connect the amp)
Power supply requirements:
- Input voltage: DC voltage regulator +5V, voltage range: 5%
- Power interface: regular TYPE-C (supports positive and negative insertion)
- Standby current: 10MA
- Operating current: >200MA
(high-quality 5V power adapter or linear regulated power supply above 500MA is recommended)

Note:
- This product does not contain power supply.
-Input power supply must meet the above power supply requirements, especially the power supply voltage.
-Anything beyond the supply voltage range or the opposite polarity of the voltage will result in damage to the machine
