Micsig DP1500 High Voltage Differential Probe with 100MHz Bandwidth 150V (50X) & 1500V (500X)
Description:
The Micsig DP Series High-Voltage Differential Probes offer selectable bandwidths from 100MHz to 500MHz, with a maximum differential input voltage of 7000Vpk. A standard BNC interface ensures compatibility with all major oscilloscope brands, while built-in metal shielding enhances anti-interference performance. The compact 2cm-thin design saves workspace and includes one-click automatic-zeroing for quick setup. Additional features include overload protection alarms and power-off memory for seamless operation.
An ultra-low noise floor (as low as 5mVrms) and dual-range design optimize the signal-to-noise ratio across different voltage levels. The high-impedance input and low input capacitance minimize loading effects, delivering ±2% measurement accuracy and excellent common-mode rejection (CMRR).
The 5 MHz bandwidth limit helps reduce high-frequency noise for accurate, high-speed differential voltage measurements. These probes are ideal for EV power systems, solar inverters, switching power supplies, and floating or isolated high-voltage signal testing.
Features:
Excellent Amplitude Frequency Characteristics
* The amplitude fluctuation within half the bandwidth is less than 0.5 dB, ensuring excellent bandwidth flatness and maintaining high accuracy in high-frequency ranges.
High Accuracy and High CMRR
* The DP Series features high input impedance and low input capacitance, minimizing loading effects and greatly improving differential signal accuracy. With high common-mode rejection (CMRR), it reliably handles floating measurements of high common-mode voltages at high frequencies.
Low Noise
* The extremely low noise floor enhances measurement sensitivity, enabling accurate detection of small signal changes.
5MHz Bandwidth Limit (available on 100–200MHz bandwidth only)
* When measuring FET switching frequencies in most switching power supplies, it effectively eliminates high-frequency noise.
BNC Interface
* Standard BNC interface, compatible with any oscilloscope.
Stronger Anti-Interference Ability
* Built-in metal shielding for greater durability and enhanced anti-interference performance.
Package Included:
* 1 x Set of Differential Probe
Packaging Details:
* Weight: 1kg
Note:
* Oscilloscope is not included.
