Details | |
Product code | RBD53iG-5HacD2HnD |
Architecture | ARM 32bit |
CPU | IPQ-4019 |
CPU core count | 4 |
CPU nominal frequency | 716 MHz |
Dimensions | 251 x 129 x 39 mm |
RouterOS license | 4 |
Operating System | |
Size of RAM | 256 MB |
Storage size | 128 MB |
Storage type | NAND |
Tested ambient temperature | -40°C to 70°C |
MTBF | Approximately 100'000 hours at 25C |
Details | |
Wireless 2.4 GHz Max data rate | 300 Mbit/s |
Wireless 2.4 GHz number of chains | 2 |
Wireless 2.4 GHz standards | 802.11b/g/n |
Antenna gain dBi for 2.4 GHz | 3 |
Wireless 2.4 GHz chip model | IPQ-4019 |
Wireless 2.4 GHz generation | Wi-Fi 4 |
Wireless 5 GHz Max data rate | 867 Mbit/s |
Wireless 5 GHz number of chains | 2 |
Wireless 5 GHz standards | 802.11a/n/ac |
Antenna gain dBi for 5 GHz | 5.5 |
Wireless 5 GHz chip model | IPQ-4019 |
Wireless 5 GHz generation | Wi-Fi 5 |
AC speed | AC1200 |
Details | |
10/100/1000 Ethernet ports | 5 |
Number of 1G Ethernet ports with PoE-out | 1 |
Details | |
Number of USB ports | 1 |
USB Power Reset | Yes |
USB slot type | USB type A |
Max USB current (A) | 1 |
Details | |
PoE in | Passive PoE |
PoE in input Voltage | 18-28 V |
Number of DC inputs | 2 (DC jack, PoE-IN) |
DC jack input Voltage | 12-28 V |
Max power consumption | 30 W |
Max power consumption without attachments | 12 W |
FAN count | Passive |
Details | |
PoE-out ports | Ether5 |
PoE out | Passive PoE |
Max out per port output (input < 30 V) | 0.5 A |
Max total out (A) | 0.5 A |
Details | |
Certification | CE, FCC, IC, EAC, ROHS |
Details | |
Mode button | Yes |
2.4 GHz | Transmit (dBm) | Receive Sensitivity |
1MBit/s | 25 | -100 |
11MBit/s | 25 | -94 |
6MBit/s | 26 | -96 |
54MBit/s | 23 | -78 |
MCS0 | 26 | -96 |
MCS7 | 22 | -73 |
5 GHz | Transmit (dBm) | Receive Sensitivity |
6MBit/s | 26 | -96 |
54MBit/s | 22 | -80 |
MCS0 | 26 | -96 |
MCS7 | 21 | -75 |
MCS9 | 19 | -70 |
