• MOXA EDS-2005-ELP 5 Port Ethernet Switch Entry-Level Unmanaged Ethernet Switch with Plastic Housing

MOXA EDS-2005-ELP 5 Port Ethernet Switch Entry-Level Unmanaged Ethernet Switch with Plastic Housing

Availability: In stock, usually dispatched in 1 business day

  • Price:$86.56
  • Price in reward points: 866 Reward Points: 9
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $84.83 $83.10 $80.50 $77.04 Contact US
Quantity:

MOXA EDS-2005-ELP 5 Port Ethernet Switch Entry-Level Unmanaged Ethernet Switch with Plastic Housing

Features and Benefits:

• 10/100BaseT(X) (RJ45 connector)
• Compact size for easy installation
• QoS supported to process critical data in heavy traffic
• IP40-rated plastic housing

Introduction:
The EDS-2005-ELP industrial Ethernet switch has five 10/100M copper ports and a plastic housing, which is ideal for applications that require simple industrial Ethernet connections. Moreover, to provide greater versatility for use with applications from different industries, the EDS-2005-ELP also allows users to enable or disable the Quality of Service (QoS) function, and broadcast storm protection (BSP) with DIP switches on the outer panel.

The EDS-2005-ELP has a 12/24/48 VDC single power input, DIN-rail mounting, and high-level EMI/EMC capabilities. In addition to its compact size, the EDS-2005-ELP has passed a 100% burn-in test to ensure it will function reliably after it has been deployed. The Ethernet switch has a standard operating temperature range of -10 to 60°C.

Package Included:
• 1 x Ethernet Switch
• 1 x Quick Installation Guide
• 1 x Warranty Card

Packaging Details:
• G.W.: 0.35kg
