MOZA R21 V1 21Nm Direct Drive Wheel Base DD Wheel Base with NexGen Force 3.0 Force Feedback System

MOZA R21 V1 21Nm Direct Drive Wheel Base DD Wheel Base with NexGen Force 3.0 Force Feedback System

Features:
21 Nm of High Torque Delivers Powerful Performance
* The wheel base features a professional-grade servo direct drive with powerful output.
* With 21 Nm of high torque, it covers the steering forces from performance cars to F1 race cars, precisely conveying vehicle dynamics and road surface details. It meets training needs from gaming to real-world driving, delivering an authentic, professional-grade simulated racing experience.

Brand-New NexGen Force 3.0 Force Feedback System
* Based on years of research in direct drive force feedback algorithms, we've launched the NexGen Force 3.0 feedback system. It significantly enhances instantaneous response and vibration filtering algorithms across different frequency bands.
* Powered by this system, the extremely high torque conversion rate and 280MHz processor enable excellent force feedback responsiveness. Vibrations across all frequency bands are better preserved, realistically and completely conveying road surface details.

Innovative Road Surface Perception Equalizer for Immersive Driving Scenarios
* MOZA has innovatively introduced the Road Surface Perception Equalizer. It enables scene-based fine-tuning of road feedback vibrations, maximizing the retention of useful details for the driver. It filters out unnecessary vibrations, creating an exceptional sense of immersion during driving.

Self-Developed Force Feedback Curve Adjustment for Confident Professional Control
* Our independently developed force feedback curve adjustment feature allows for a nonlinear relationship between the base's force output and game commands. It amplifies dynamic feedback that aids in driving while diminishing distracting forces. This enables drivers to more easily sense vehicle loss of control, improves tolerance at the handling limit, and allows them to drive confidently on the edge.

Six Core Technologies
* Meticulously designed by Chinese motor experts, the rotor adopts innovative structures such as V-shaped skewed pole fractional slots and concentrated windings.
* With the same volume, it delivers over 30% more maximum torque than the R16.
* Further optimization of torque ripple and cogging torque provides a smoother steering experience.

High-Strength Aluminum Alloy Body
* The body is largely constructed from aluminum alloy, offering both rigidity and a premium tactile feel.

High-Performance Motor, Born Exceptional
* The powerful motor, custom-designed for sim racing scenarios and optimized by Chinese motor experts, incorporates high-grade neodymium-iron-boron magnets and high-permeability magnetic cores. This results in lower cogging torque and torque ripple, delivering an incredibly smooth steering feel.

18-bit Magnetic Encoder
* The motor is controlled by an 18-bit magnetic encoder, dividing each rotation into 262,144 segments for more refined steering feedback.
* With faster response, it significantly enhances the competitive driving experience.

Professional Conductive Slip Ring: Stable and Durable
* The conductive slip ring ensures a robust connection between the base and the steering wheel, supporting high-speed rotation with an operational lifespan of up to 5 million revolutions (according to MOZA laboratory durability tests). It offers stable performance and long-lasting reliability.
* Wireless communication is also supported. With a dual-connection design, it ensures a secure link without disconnection.

Intelligent Temperature Control
* MOZA's self-developed intelligent thermal management system continuously monitors the motor's temperature and adopts different cooling strategies based on real-time thermal data. This ensures the safe and stable operation of the equipment.

Supports Multi-Device Integration
* Users can directly connect MOZA ecosystem devices such as pedals, shifters, handbrakes, and dashboards to the base. This not only reduces the number of USB ports needed but also allows for unified use of multiple devices on the same console platform.

Front Mounting Support
* The front of the base features four mounting holes.
* When paired with MOZA's front mounting bracket, both front and side mounting options are available. This improves legroom and is especially suitable for a Formula-style seating position.
*Note: The front mounting bracket is sold separately.

Mobile App Cloud-Based Control
* Through the mobile app, users can adjust settings for the base, steering wheel, pedals, and other devices.
* Parameter tuning can be performed during a race without pausing or switching screens.
* Main functions in the Pit House control center can be managed via a smartphone or tablet.

Quick Launch for Instant Gameplay
* With MOZA's proprietary control center, MOZA Pit House, once configured, users can launch directly into the game with a single click—no more waiting, just start playing instantly.

Specifications:
* Supported Platform: PC
* Drive Type: Direct Drive
* Maximum Steering Angle: 90°–2700°
* Housing Material: Aluminum Alloy
* Maximum Torque: 21 Nm
* Rated Power: 480W
* Input Voltage: 110V–220V AC → 36V DC
* Encoder Resolution: 262,144 PPR
* Maximum USB Refresh Rate: 1000 Hz
* App Functionality: Supported
* Quick Release: Supported
* Ports: Power Supply, Data, Pedal, Display, Shifter, Handbrake, and Emergency Stop Switch
* Accessories: User Manual, Power Supply, Data Cable, and Screw Kit
* Mounting Method: Front-mounted with 4 holes / Bottom-mounted with 4 holes
* Mounting Bracket: Bottom Angle-Adjustable Bracket / Side-Mount Bracket
* Table Clamp: Optional
* Side Mounting: Supported
* Emergency Stop Switch: Optional
* Firmware Upgrade Function: Supported

Partial Game Compatibility List:
* For Assetto Corsa
* For Assetto Corsa Competizione
* For DiRT Rally
* For DiRT Rally 2.0
* For DiRT 4
* For F1 2018
* For F1 2019
* For F1 2020
* For Kartkarft
* For BeamNG.Drive
* For MudRunner
* For WRC 9
* For WRC 10
* For WRC G
* For Richard Burns Rally
* For Live For Speed
* For F1 2021
* For F1 22
* For Forza Horizon 4 (Version for Microsoft Store)
* For Forza Horizon 5
* For Project CARS
* For Project CARS 2
* For Project CARS 3
* For Wreckfest
* For RaceRoom Racing Experience
* For Automobilista
* For Automobilista 2
* For iRacing
* For rFactor 2
* For Euro Truck Simulator 2
* For American Truck Simulator
* For American Truck Simulator 2

Packing List:
* 1 x Set of wheel base

Packaging Details:
* Weight: 13.1kg
