Oled Digital Display RF Power Meter 50Mhz-3000Mhz -45-+5dBm Attenuation Value RF-Power3000

Tags: RF Power Meter

Availability: In stock, usually dispatched in 1 business day

  • Price:$29.94
  • Price in reward points: 299 Reward Points: 3
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $29.34 $28.74 $27.84 $26.65 Contact US
Quantity:

Oled Digital Display RF Power Meter 50Mhz-3000Mhz -45-+5dBm Attenuation Value RF-Power3000

User Manual Link      Password:r5bu

RF-Power3000 Parameter:
1.Measuring power range:-45-+5dBm(external RF attenuator can be extended to 100dBm)
2.The measurement resolution of:0.1 dBm power
3.Measurement frequency range:50Mhz-3000Mhz
4.The measured power:1nW~2W
5.The working voltage of 5VDC can work MICRO-USB powered)
6.The working current:<50 mA
7.Error:<+-1dB
8.Dynamic range:>50dB
9.The working temperature of:-40 ℃~65 ℃ degrees Celsius
10.Storage temperature:-40 ℃~65 ℃ degrees Celsius
11.Size:50x50x25mm(LxWxH)

Fourth,the RF common sense science:

dB is a pure count of unit:
For power,dB = 10xlg (A/B).
For voltage or current,dB = 20 * lg (A / B).
dBm is defined miliwatt (mW).0 dBm = 1mw;
dBw defined watt.0 dBW = 10lg1 W = 10lg1000 mw = 30 dBm.
dB power units are always defined by default,to 10lg for scoring.Of course,some cases may signal strength (Amplitude) to describe the work and power,this time with 20lg for scoring.Whether in the field or control signal processing field like this.For example, sometimes you can see the expression dBmV.
