Pololu 3Pi Robotic Car ATmega168/328P Line-Following Line-Maze-Solving LCD Robot

Availability: In stock, usually dispatched in 1 business day

  • Price:$304.38
  • Price in reward points: 3044 Reward Points: 30
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $298.29 $292.20 $283.07 $270.90 Contact US
Quantity:

Pololu 3Pi Robotic Car ATmega168/328P Line-Following Line-Maze-Solving LCD Robot

Parameters:

- Product name: 3Pi Robot Pololu
- Weight: 83g
- Size: diameter 9.5cm
- Speed: 100cm/ seconds (under4AAA battery)
- Processor: ATmega168/328P
- Motor drive: TB6612FNG
- Motor number: 2
- Available I/O port: 21
- Minimum working voltage: 3.2V
- Maximum working voltage: 7.2V
- PWM, the maximum frequency: 80 kHz

Product features:
- Maximum speed of 1, about 100 cm / sec
- Motor voltage (performance is not affected by the voltage of a battery)
- 8x2 character LCD debugging, feedback and user interface
- Piezoelectric buzzer, simple voice and music

Pololu 3pi Robot User’s Guide: Click here
Pololu AVR Programming Quick Start Guide: Click here
Pololu AVR C/C++ Library User’s Guide: Click here
Pololu AVR Library Command Reference: Click here
Building Line Following and Line Maze Courses: Click here
Programming Orangutans and the 3pi Robot from the Arduino Environment: Click here
Sample Project: 3pi Wall Follower: Click here
Sample Project: RC 3pi: Click here

File downloads:
1.3pi quick-start sheet and schematic(486k pdf): Click here
2.3pi simplified schematic diagram(481k pdf): Click here
3.Pololu 3pi Robot guia de usuario(3MB pdf): Click here
4.Line Maze Algorithm Presentation(505k pdf): Click here

Package included:
- 1 x Pololu 3Pi Robot
