PTS300D T12 70W Cordless Soldering Station Battery Powered Soldering Iron Station for Dewalt Battery

PTS300D T12 70W Cordless Soldering Station Battery Powered Soldering Iron Station for Dewalt Battery

Features:
- Portable soldering iron station: It supports up to 70W and is DC powered, with rich menus.
- Convenient to operate: It is easy to operate the soldering station with one hand.
- Professional workmanship: Made from high-quality materials, it is durable and has a long service life.
- Fast heating and adjustable temperature: The soldering station can heat up quickly. Temperature read-outs are displayed via a digital display and you can turn the knob to set the temperature precisely.
- Lead-free solder of compact size: The cordless soldering station helps save precious work space. Lead-free soldering tip and soft handle make it more comfortable to use during long term soldering projects.
- Safe to use: Quality materials are used. With built-in low-voltage protection and automatic cooling mode. When it is not used, the handle can be placed on the handle frame, the machine will cool automatically, and the temperature will rise rapidly when the handle is picked up.
- Compatibility: For DEWALT 20V/60V Flex XR slide style battery packs. The portable soldering station helps get your soldering job done in a more convenient and faster way.

Specifications:
- Power: 70W maximum
- Working voltage: 12-24V
- MCU: 32bit M1
- Screen: 1.77-inch TFT
- Condition: 100% new
- Weight: about 0.33kg/0.7lb
- Size: 22 x 11.2 x 6.1cm/8.7 x 4.4 x 2.4"
- Temperature unit: ℃/℉

Package Included:
- 1 x Soldering Station (without battery)
- 1 x Handle with Heating Element

Note:
- Battery is not included.
- If you are not sure whether your battery is suitable for the product, please contact us before purchasing.

Basic operation:
1. In the normal mode, short press the encoder to enter the preset temperature mode (four groups of common temperatures are preset according to your own needs, and the rotary encoder can cycle through these four groups of preset temperatures), and then short press again to enter the set temperature mode. Each time you rotate the encoder, the temperature will increase by 10℃, and the step temperature is adjustable!
2. In the normal mode, long press the encoder to enter the setting menu and short press to select. Short press again to cancel the selection, and long press the encoder in the menu interface to exit and return to the previous level!

Important notes for T12 welding station:
If you enter the menu to change the parameters or restore the factory settings, be sure to pay attention to the following parameters to be set correctly, otherwise there will be errors and other abnormalities!
1. The sleep time must be set to "0", otherwise the sleep seat function will become invalid. (Time setting in main menu → Sleep time → Set to 0.
2. The standby time is set to 10 (time setting in the main menu → standby time → set to 5 or 10, and you can set any length of time according to your needs).
3. Under voltage protection, it is set to 15 or 16 (other settings in the main menu → voltage protection → set to 16).
4. Sleep temperature setting (temperature setting in main menu → sleep temperature → set to 60).
5. Maximum temperature setting (temperature setting in main menu → maximum temperature → 420).
6. If you use T12 heating element, please select T12 as the heating element model (main menu → other settings → nozzle selection → T12).
