PW-810 High Performance Power Inverter Handmade Nano Amorphous Machine Single Silicon Post Stage

PW-810 High Performance Power Inverter Handmade Nano Amorphous Machine Single Silicon Post Stage

Description:
- Amorphous machine is a transformer made of nano amorphous magnetic cores. Nano amorphous magnetic cores are a material with outstanding magnetic conductivity, using rapid cooling solidification production process. Their physical state is characterized by disordered amorphous arrangement of metal atoms, which is completely different from the crystal structure of silicon steel and is more conducive to magnetization and demagnetization. A typical amorphous alloy contains 80% iron, while the other components are boron and silicon.

Features:
- The post stage drive uses two 1800V thyristor parallel outputs, and the post stage inductor has always adhered to the use of expensive hollow inductors used on fever level speakers, ensuring continuous and stable power and exceptional results.
- 6 new 340A ultra high current power tubes are used to push the main transformer (one pair of power tubes can be tested to produce 1200W without exploding tubes), and two 400A power tubes are used for reverse protection.
- High voltage electrolytic capacitor is upgraded to electrolytic capacitor for NCC.
- High and low voltage conversion
- Mixing function
- One click enhancement function
- Equipped with reverse connection protection, water fall protection, short circuit protection, and over temperature protection (machine protection above 60 degrees Celsius).
- The machine is equipped with a 1000W sun lamp, with an actual input current exceeding 100A and a power exceeding 1200W
- Size: L x W x H = 14 x 8.2 x 4.2cm; weight: 0.82kg
- It can be started with 20AH battery; above 32AH, supporting three strings of polymer slow point 12.6V and four strings of Lithium iron phosphate full charge 14.8V.

Package Included:
- 1 x Power Inverter

Note:
- Battery is not included.
