RS485 / Alarm 8CH Video BNC Input Network Security CCTV DVR System 1000GB HDD IN

Availability: In stock, usually dispatched in 1 business day

  • Price:$309.84
  • Price in reward points: 3098 Reward Points: 31
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $303.64 $297.45 $288.15 $275.76 Contact US
Quantity:

RS485 / Alarm 8CH Video BNC Input Network Security CCTV DVR System 1000GB HDD IN


Product Overview

The kit includes a 8CH H.264 standalone DVR,8 48LED SONY CCD 600TVL security Armor cameras ,FREE 1000GB HDD ,FREE AUDIO/VIDEO/POWER cable , FREE CAMERA /DVR power supply, quickly and easily install.

This DVR with windows style OSD interface will help you to operate the DVR easier,fully integrated, real time, and hardware based standalone digital video recorder. With PTZ camera control, network access, motion detection, USB backup, this DVR is perfect for the home or small businesses. The DVR also features the most updated 3G mobile live preview technology.

This Camera is a day/night weatherproof security camera ,with 66ft night vision.Uses us free for you cable, connects dvr to camera, Create your own security system

Real-time surveillance
· analog interface and VGA interface (VGA interface is equipped selectively)
· surveillance function through monitor or display
Storage
· non-working hard disk dormancy processing which is convenient to radiate heat, reduce power and extend the life-span
· special storage format which insures the data safety
Compression
· real-time compression by individual hard disk which insures the audio and video signal stable synchronization
Backup
· through SATA interface and USB interface such as USB equipment, removable hard disk and so on
· through net download the files in the hard disk
Playback
· individual real-time video recording as well as searching, playback, network surveillance, recording check,downloading and so on
· multi-channel playback mode
· zoom at arbitrary region
Net operating
· through net tele-surveillance in the real time
· remote control PTZ
· remote check the recording and real-time playback
Alarm linkage
· only one channel relay alarm output which is convenient for the alarm linkage and light control at the spot
· protecting circuits at the alarm input and output interface which protects the main machine from damage
Communication interface
· RS485 interface which fulfills the alarm input and PTZ control
· standard ethernet network interface which fulfills the telecommuting function
Intelligent operating
· mouse action function
· fast copy and paste operating for the same setting

DVR Specifications:

Model D19108

Video Compression

H.264

Video System

NTSC / PAL

Operation System

Windows / Linux

Video Input / Output

BNC 8-channel inputs / 1-channel outputs

Audio Compression

8kHz*16bit ADPCM

Audio Input / Output

RCA 8-channel inputs / 1-channel outputs

Display Frame Rate

PAL: 200 fps / NTSC: 240 fps

Playback Resolution

PAL: CIF(352x288), HD1(704x288), D1(704x576)
NTSC: CIF(352x240), HD1(704x240), D1(704x480)

Total Recording Frame Rate

PAL: 200fps@CIF
NTSC: 2400fps@CIF

Recording Mode

Always / schedule / motion detection / sensor triggered

Recording Pack Time

15/30/45/60mins selectable

HDD Interface

Support SATA HDD & USB disk

Ethernet

RJ45, 10M/100M

Network Protocol

Support TCP/IP, UDP, DHCP, DNNS, PPPoE

Network Function

Support preview live display remotely via mobile phone and real time monitoring via IE-based browser and/or network, and support parameter setting of DVR remotely

USB2.00

USB mouse, USB disk (backup, upgrade)

Playback Mode

Normal play, fast forward, fast rewind, frame by frame

Backup

Backup AVI file via USB flash disk, USB disk, USB CD/DVD-RW & Network

PTZ Control

Built-in RS485, support PELCO-P & PELCO-D

Alarm Mode

Motion Detection, Sensor triggered, video loss, HDD error, HDD full

Alarm

1 alarm output

Power Supply

DC 12V/5A (power adaptor included)

Power Consumption

10~15W

Working Temperature

-10°C to +40°C

Working Humidity

10% to 90%

 Package Includes:
- 1 x 8 Channel H.264 Network Stand-alone Digital Video Rcorder
- 1 X 1000GB HDD
- 1 x Power Adaptor for Stand-alone DVR
- 1 x Power Cord for Stand-alone DVR
- 1 x Remote Controller for Stand-alone DVR
- 1 x Mouse for Stand-alone DVR
- 1 x CABLE connect Stand-alone DVR to TV
- 1 x CD SOFTWARE
- 1 x User manual (English)
