T-Motor U12 II KV60 Outrunner Brushless Motor U Efficiency Type Max Thrust 20.4KG IP55 1500 Flights

T-Motor U12 II KV60 Outrunner Brushless Motor U Efficiency Type Max Thrust 20.4KG IP55 1500 Flights

Features:
- U12 II-a leap of thrust improvement
- Redesigned iron core; sine wave features; FOC ESC; silver winding; innovative cooling design
- 62% payload increase
- Imported custom silver wires. Silver wires are adopted for easy control over aircraft from fast motor response speed, reliability and copper loss reduction which also helps lower motor heat by 30%
- New iron core design. The new iron core is selected after months of testing, comparison and improvement. The new design helps provide more thrust and better efficiency while maintain the best weight value
- Heavy load with maximum thrust 20.4kg. With new iron core design, max thrust reaches 20.4kg from 13.6kg, which greatly elevates an aircraft payload
- Motors work at ease in high temperature. Centrifugal air-cooling system, built-in array for efficient heat dissipation. The terrific cooling performance guarantees the reliability during even running in 50℃ environment
- Motor protection for safe flight. IP55 heavy rains and desert are not qualified to stop you from flying
- New dust prevention network. Protect motors from sand, dust, foreign matters and magnetic particles. Diameter of dust prevention network smaller than <1mm
- Iron core: special antirust treatment; passed 48h salt spray test
- Motor service life: 1500 flights are out of question (40mins/flight)
- Imported custom bearings. Simulated analyses are carried out based on the stress under operating condition in axial and radial directions. Redesign of custom bearing prolongs the bearing life to 1000h under trouble-free operation
- N42 UH arc magnet. High grade magnets improve torque for high efficiency in high temperature

Package Included:
- 1 x Motor
- 1 x Bag of Parts
