TM613 Three phases 380V Programmable Timer Switch with Backlight Motor Automatic Intelligent Controller

TM613 Three phases 380V Programmable Timer Switch with Backlight Motor Automatic Intelligent Controller

Description:
- TM613 (PATENT PRODUCT) 7 DAYS programable Stable three-phase high-performance timer switch, three FireWire input and output three FireWire, zero line without inconvenient for some customers to solve the shortcomings of the zero line, just set up a few open points off the can, a total of 17 can be set to open 17 Off , Monday to Sunday, arbitrarily set a minimum interval of one minute, the maximum 168 hours (equivalent to one week), you can manually open and close temporarily, as long as one can set up a permanent loop. It is widely used in pumps, pond aerator, steaming machines, water heaters, billboards, neon signs, exhaust fan, etc. Three-phase 350V-420VAC motors and other equipment, to achieve unmanned management, safe, reliable, stable performance, is a very good choice.

Feature:
- Three phase digital time switch for 7 days-24 hours.
- Advanced pre-setting one week before
- 17 ON/OFF programs for daily and weekly
- One channel, voltage output.
- Accurate-to-the-minute control
- LED power indicator, high contrast LCD display
- Reset function and manual override
- Battery backup for power failure

Parameter:
- Operating voltage: 380V / 50-60Hz
- Customized voltage: 12V / 24V / 110VAC
- Control output: 16A (direct), it can be used for capacity expansion control
- Setting frequency: 16 times of switching (day/week)
- Setting time: 17 minutes to 168 hours
- Travel time error: 1s/24h
- Power failure memory: 180 days
- Dimension: 120 x 120 x 52mm
- Connection mode: 35mm DIN-Rail mounted

Package Included:
- 1 x TM613 Timer Switch

Note:
- Battery is not included.
