• u-blox GPS Module LEA-6R (with Inertial Navigation Function) DIY Spare Parts

u-blox GPS Module LEA-6R (with Inertial Navigation Function) DIY Spare Parts

Availability: In stock, usually dispatched in 1 business day

  • Price:$75.90
  • Price in reward points: 759 Reward Points: 8
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $74.38 $72.86 $70.59 $67.55 Contact US
Quantity:

u-blox GPS Module LEA-6R (with Inertial Navigation Function) DIY Spare Parts

Product description:
The LEA-6R provides 100 % coverage, combining the high performance u-blox 6 positioning engine with u-blox’ ADR Dead Reckoning technology. ADR supplements GPS satellite position information with heading and distance data provided by additional sensors. When GPS satellites are out of sight, location is extrapolated using distance and angle information from the gyroscope and speedpulse sensors. The speedpulse sensor signal can be received either as a digital tick signal or as messages via the serial interface. The gyroscope is monitored via an external ADC over the SPI interface. ADR enables accurate navigation even in locations with poor or absent GPS signals such as tunnels, indoor parking facilities and deep urban canyons. In addition, ADR effectively elimi-nates the impact of multipath effects in urban canyon environ-ments. This makes the LEA-6R the ideal solution for applica- tions requiring accurate, reliable positioning, all of the time. LEA-6R modules are manufactured in ISO/TS 16949 certified sites. Each module is tested and inspected during production. Qualification tests are performed as stipulated in the ISO16750 standard: “Road vehicles – Environmental conditions and test- ing for electrical and electronic equipment”.

Highlights:
- Automotive Dead Reckoning (ADR) technology:
- 100% coverage, continuous positioning even in tunnels
- 1 Hz combined DR+GPS navigation rate
- Speedpulse sensor monitoring via I/O pin or as messages
- Gyroscope/Temperature sensor monitoring
- Automatic sensor calibration / temperature compensation
- UART and USB interfaces
- Integrated antenna supervisor
- Extra front-end LNA

Features:
- u-blox 6 position engine:
- Navigate down to –162 dBm and –147 dBm coldstart
- Hybrid GPS/SBAS engine (WAAS, EGNOS, MSAS)
- Anti-jamming technology
- Simple integration with u-blox wireless modules
- A-GPS: AssistNow Online and AssistNow Offline services,OMA SUPL compliant
- Backward compatible (hardware and firmware); easy migration from LEA-4R
- LCC package for reliable and cost effective manufacturing
- Compatible with u-blox GPS Solution for Android
- Based on GPS chips qualified according to AEC-Q100
- Manufactured in ISO/TS 16949 certified production sites
- Qualified according to ISO 16750

Download:
- LEA-6R Product Summar
- LEA-6 NEO-6 MAX-6 Hardware Integration Manual
- u-blox 6 Receiver Description Protocol

Package List:
- u-blox  GPS Module LEA-6R   X  1pcs
