Tags: Video Capture Card
Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
---|---|---|---|---|---|
Price /Unit | $228.95 | $224.28 | $217.27 | $207.92 | Contact US |
Interface:
- USB:PCIe3.0,360MB/s
- Video input:1xSDI,1xHDMI
- Video output:PCIeX1
- Video:1080P50/60,1080I50/60,720P50/60,576P,576I,480P,480I
- Audio:HDMI/SDI built-in
- Parameter:Windows (7,8,8.1,10),Linux (kernel version 2.6.38 and above),OS X (10.8 and above)
HDMI interface:
- Interface bandwidth:HDMI 1.4a compliance,Support 1080P/60HZ 8-bit,(RGB,YUV)SD/HD/3G-SDI,SMPTE-259/274/296/372/424/425/292 compliance - Video spercification:HDMI:165MHZ,SDI:1.485Gb/s,2.97Gb/
- Audio specification:UVC (USB video class) compliance
- Color space:UAC (USB audio class) compliance
- General:YUY2
Operating system:
- Compatible software:Support x86 & x64 from Windows 7,8.1、10,Windows Server 2008 R2
- Compatible development tool:Vmix,Wirecast,OBS,Windows Media Encoder,Adobe Flash Media Live Encoder,Real Producer Plus,VLC,Wire cast,AMCAP etc.
- Upgrade:DirectShow (Windows),DirectSound(Windows),Firmware can upgrade
- Size:20x100x122mm
- Power consumption:<= 3.5 W
- Storage temperature:0-50 degree
- Storage humidity:-20-70 degree
