UNI-T 50MHz 500Ms/s Digital Storage Oscilloscopes DSO Dual Channels 7 inch LCD Scopemeter w/Probe UTD2052CL

UNI-T 50MHz 500Ms/s Digital Storage Oscilloscopes DSO Dual Channels 7 inch LCD Scopemeter w/Probe UTD2052CL

Description:
1. Dual analog channels width range 1mV/div~20V/div;
2. 7 inches widescreen LCD displays;
3. Special Print Scree Feature;
4. Supports plug-and-play USB storage device. Communication with and remote control of computer through the USB device;
5. USB drive system software upgrade;
6. Storage of waveforms setups and interfaces waveforms and setups reproduction;
7. Automatic measurement of 28 waveform parameters;
8. Unique waveform recording and replay function;
9. Multilingual menu displays.

Specification:
- Model: UTD2052CL
- Channels: 2
- Bandwidth: 50MHz
- Sample Rate: 500Ms/s
- Rise Time: ≤7ns
- Memory Depth: 25kpts
- Waveform Acquisition Rate: ≥2000wfms/s
- Vertical Sensitivity: 1mV/div~20V/div
- Timebase Range: 5ns/div~50s/div
- Storage: Setup,Wave,Bitmap
- Trigger Modes: Edge, Pluse, Alternate
- Interface: USB OTG

Features:
- Product Net Weight: 2.2 Kg
- Product Size:306mm * 147mm * 122mm
- Display: 7 Inches 64K Color TFT  LCD,  400×240
- Product Color: White and Gray
- Package Weight: 8.5kg

Package List:
- 1 * UNI-T UTD2052CL Digital Storage Oscilloscope
- 1 * Power Cable
- 1 * USB Cable
- 1 * PC Software CD
- 1 * Manual
- 2 * Test Probes(1×,10× switchable)
