UNI-T UDP6731 360W 80V 15A Programmable Power Supply Regulated DC Power Supply with 2.8" LCD Display

UNI-T UDP6731 360W 80V 15A Programmable Power Supply Regulated DC Power Supply with 2.8" LCD Display

Description:
The UDP6730/UDP6731 wide-range programmable switchable DC power supplies support wide output ranges of 40V/30A and 80V/15A, respectively. They feature industry-leading wide-range voltage/current utilization, greatly expanding the range of applications. With an output power of 360W, they automatically control the rate of change of voltage and current, achieving a power ratio up to three times. The entire series uses high-definition LCD displays, comes standard with an RS-232 communication interface, and supports the SCPI protocol, facilitating remote control. Its remote compensation module can prevent testing inaccuracies caused by voltage drops on load lines. The products also feature low ripple noise, high-precision voltage/current output, and multiple protection functions to ensure reliable operation.

Advantages:
RS232 Remote Communication for Easier Control
* It comes standard with an RS232 communication interface and upper-computer software. Using this software, users can easily perform remote control of the power supply system, set output voltage and current, and save data.

Remote Compensation Setting (up to 1V) for More Accurate Measurement
* It provides a remote compensation function. By connecting the voltage signal at the load end to the remote compensation terminal, users can activate this function. Using compensation ensures that the output voltage at the load end is no longer affected by current magnitude or voltage drop along the load lines, keeping the output voltage at the set value and ultimately ensuring voltage accuracy.

Fully Digital Control with Wider Adjustment Range
* The UDP6730/UDP6731 switchable DC power supplies feature industry-leading wide-range voltage/current utilization. Under a fixed power rating, they can provide various combinations of voltage and current outputs. A single power supply can meet the testing needs of devices requiring either high voltage with low current or low voltage with high current. They automatically control the rate of change of voltage and current, achieving a power ratio up to three times, greatly expanding the range of applications.

List Mode & Delay Timer Function
* The list mode allows setting up to 48 groups of arbitrary voltage and current outputs, with adjustable output intervals. It also provides output waveform preview and output cycle settings, enabling true online programming. The delay timer function provides 48 preset switch states and allows setting of protective voltage thresholds.

2.8-inch True-Color LCD Display
* It provides a feature-rich, easy-to-use human–machine interface, using a 2.8-inch high-definition LCD display. Readings are clear at a glance, and operation is simple and intuitive. It can display in real time the current set output voltage/current, actual output voltage/current, and protection output voltage/current. Users can also easily configure system settings, providing a user-friendly experience that meets the diverse testing needs of engineers.

Features:
* Fully digital control
* High resolution: 10mV/1mA
* Low ripple and low noise
* Software calibration function
* Compact size
* High-definition LCD display
* Remote compensation
* Supports RS232 communication
* Intelligent fan speed control
* High reliability: over-voltage/over-current/over-temperature protection
* Multiple preset output voltage/current groups: 3 × 200 groups
* Supports list mode (timing function) and delay timer function
* Upper-computer operation software available

Packing List:
* 1 x Power Supply
* 1 x Power Cable
* 1 x Certificate of Conformity
* 1 x Warranty Card
* 1 x Upper-Computer Software and Documentation Download Guide

Packaging Details:
* Weight: 5kg
