SPECIFICATIONS
| Basic Functions | Range | Best Accuracy | |||
|---|---|---|---|---|---|
| DC Voltage | 400mV/4V/40V/400V/1000V |  (0.8%+1) | |||
| AC Voltage | 4V/40V/400V/750V | (1%+5) | |||
| DC Current | 400mA/4000mA/40mA/400mA/4A/10A | (1%+2) | |||
| AC Current | 400mA/4000mA/40mA/400mA/4A/10A | (1.5%+5) | |||
| Resistance | 400W/4kW/40kW/400kW/4MW/40MW | (1%+2) | |||
| Capacitance | 40nF/400nF/4mF/40mF/100mF | (3%+5) | |||
| Frequency | 10Hz-10MHz | (0.1%+3) | |||
| Duty Cycle | 0.1%~99.9% |  | |||
| Special Functions | |||||
| Fused 10A Range | | ||||
| Auto Ranging | | ||||
| Diode | | ||||
| Continuity Buzzer | | ||||
| Relative Mode | | ||||
| Data Hold | | ||||
| Display Backlight | | ||||
| Full Icon Display | | ||||
| Sleep Mode | | ||||
| Low Battery Display | | ||||
| Input Impedance for DC Voltage Measurement | Around 10MW | | |||
| Max Display | 3999 | | |||
GENERAL CHARACTERISTICS
| Power | 9V Battery (6F22) |
| LCD Size | 63 x 31mm |
| Product Colour | Red and Grey |
| Product Net Weight | 340g |
| Product Size | 177 x 85 x 40mm |
| Standard Accessories | Test Lead, Battery, English Manual, Test Clip |
| Optional Accessories* | Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2) |
| Standard Packing | Gift Box |
| Standard Quantity Per Carton | 40 pcs |
| Standard Carton Measurement | 595 x 400 x 326mm (0.078 CBM Per Standard Carton) |
| Standard Carton Gross Weight | 21kg |
