| Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
|---|---|---|---|---|---|
| Price /Unit | $52.59 | $51.51 | $49.90 | $47.76 | Contact US |
QLeTEK KL500A 100V 500A Bluetooth Smart Battery Monitor Coulometer Voltmeter Voltage Current Meter
$59.85
QLeTEK KL300A 100V 300A Bluetooth Smart Battery Monitor Coulometer Voltmeter Voltage Current Meter
$49.96
QLeTEK KL150A 100V 150A Bluetooth Smart Battery Monitor Coulometer Voltmeter Voltage Current Meter
$43.95
SPECIFICATIONS
| Basic Functions | Range | Best Accuracy |
|---|---|---|
| DC Voltage | 340mV/3.4V/34V/340V/1000V |  (0.8%+1) |
| AC Voltage | 3.4V/34V/340V/750V | (1.5%+3) |
| Bandwidth | 100kHz-3db | |
| DC Current | 340mA/3400mA/34mA/340mA/10A | (1.2%+2) |
| AC Current | 340mA/3400mA/34mA/340mA/10A | (1%+3) |
| Resistance | 340W/3.4kW/34kW/340kW/3.4MW/34MW | (1%+2) |
| Frequency | 3.4kHz/34kHz/340kHz/3.4MHz/34MHz | (0.2%+2) |
| RPM | 34k/340k/3.4M/34M/340M | (0.2%+2) |
| Special Functions | ||
| Fused 10A Range |  | |
| Auto Ranging | | |
| Diode | | |
| Continuity Buzzer | | |
| Data Hold | | |
| RS232C | | |
| Display Backlight | | |
| Full Icon Display | | |
| Sleep Mode | | |
| Low Battery Display | | |
| Input Impedance for Voltage Measurement | Around 10MW | |
| Max. Display | 3400 |
GENERAL CHARACTERISTICS
| Power | 9V Battery (6F22) |
| LCD Size | 63 x 31mm |
| Product Colour | Red and Grey |
| Product Net Weight | 320g |
| Product Size | 177 x 85 x 40mm |
| Standard Accessories | Test Lead, Battery, English Manual, Test Clip, RS232C Interface Cable, Software |
| Optional Accessories* | Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2) |
| Standard Packing | Gift Box |
| Standard Quantity Per Carton | 40 pcs |
| Standard Carton Measurement | 595 x 400 x 326mm (0.078 CBM Per Standard Carton) |
| Standard Carton Gross Weight | 24.2kg |
