X885 V1.2 SATA HDD Expansion Board Dual 3.5" SATA HDD Shield for Raspberry Pi 4 Model B 8GB/4GB/2GB
Description:
This X885 SuperSpeed USB to dual SATA Gen3 ports shield makes it easy to add high-capacity, high-performance external data storage to your board for Raspberry Pi 4. The dual SATA shield supports two 3.5" SATA hard drives with ultra-fast data transfer speeds and configurable RAID modes. This dual SATA shield delivers fast file transfer rates up to 5Gbps with USB 3.1 Gen 1 performance. It supports SATA I, II and III and is enhanced with UASP to maximize the performance and speed of your SATA III drives. The dual SATA shield provides an effective solution for Raspberry Pi4 to store, access, back up, and protect important files.
Features:
- Ideal storage solution for Raspberry Pi 4 - Dual SATA Gen3 ports Shield
- Create high performance storage with a dual SATA HDD RAID array through USB 3.1 (5Gbps)
- Supports Standard Desktop 3.5" SATA Hard Drives or SSD
- Supports hard drives up to 10TB
- Supports SATA I, II and III and is enhanced with UASP to maximize the performance and speed of your SATA III drives
- Supports Transfer Speeds up to 5Gbps (USB 3.0), 480Mbps (USB 2.0), 12Mbps (USB 1.1)
- For hardware JBOD, RAID0 (striping), RAID1(mirror) and Normal mode
- Supports mode select via jumper setting
- Plug and play and no drivers needed
- LED blue indicator indicates each drive status
- Onboard push button to control power on, safe shutdown, reboot and force shutdown
- Supports full power-off from software
- Onboard red LED shows the status of power on, reboot and shutdown
- Powers the board for Raspberry Pi via the 40pin header - no additional cabling required
- Specially made USB3.0 jumper to connect with board for RaspberryPi - no additional cables needed
- Onboard PH2.0 connectors for external switch and PWM cooling fan
- Mounting holes and standoffs provide mechanical stability of the board for RaspberryPi and X885 assembly
How to Power?
- Power supply: 12Vdc +/-5% , ≥5A, via DC 12V IN Port of X885
- Ports & Connectors: DC jack - 5.5x2.1mm
- Important Note: Please use high quality power adapter, the low quality PSU may damage the X885 board and not recognized the HDD.
More Information:
wiki.geekworm.com/X885
Packing List:
- 1 x Set of X885 Dual 3.5" SATA HDD Shield
Note:
- The board for Raspberry Pi and HDD are not included.
