0.01-8GHz 50ohms DC Bias Tee RF Feedback High Current DC Block with SMA Female to Female Connector

Availability: In stock, usually dispatched in 1 business day

  • Price:$43.74
  • Price in reward points: 437 Reward Points: 4
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $42.87 $41.99 $40.68 $38.93 Contact US
Quantity:
Buy it now Add cart

You might like

  • $0.00
  • $0.00
  • $0.00
0.01-4.2GHz 50ohms DC Bias Tee RF Feedback High Current DC Block with SMA Female to Male Connector

0.01-4.2GHz 50ohms DC Bias Tee RF Feedback High Current DC Block with SMA Female to Male Connector

$28.19

(0)
0.01-4.2GHz 50ohms DC Bias Tee RF Feedback High Current DC Block with SMA Male to Female Connector

0.01-4.2GHz 50ohms DC Bias Tee RF Feedback High Current DC Block with SMA Male to Female Connector

$28.19

(0)
0.01-4.2GHz 50ohms DC Bias Tee RF Feedback High Current DC Block with Stainless Steel SMA Female to Female Connector

0.01-4.2GHz 50ohms DC Bias Tee RF Feedback High Current DC Block with Stainless Steel SMA Female to Female Connector

$32.08

(0)
0.01-4.2GHz 50ohms DC Bias Tee RF Feedback High Current DC Block with SMA Female to Female Connector

0.01-4.2GHz 50ohms DC Bias Tee RF Feedback High Current DC Block with SMA Female to Female Connector

$28.19

(0)
HamGeek 1MHz-6GHz HackRF One R10 V2.0.x + PortaPack H2M w/ Built-in Speaker + 5 Antennas + USB Cable

HamGeek 1MHz-6GHz HackRF One R10 V2.0.x + PortaPack H2M w/ Built-in Speaker + 5 Antennas + USB Cable

$165.34

(0)
Gold-plated Connector 0.01-6GHz RF Bias Tee 2A High Current DC Block with SMA Female Connector

Gold-plated Connector 0.01-6GHz RF Bias Tee 2A High Current DC Block with SMA Female Connector

$34.02

(0)
Stainless Steel Connector 0.01-6GHz RF Bias Tee 2A High Current DC Block with SMA Female Connector

Stainless Steel Connector 0.01-6GHz RF Bias Tee 2A High Current DC Block with SMA Female Connector

$37.91

(0)
0.01-3GHz 3A High Current Bias Tee 50V RF DC Block 50ohms RF Coaxial Feed with N-Type Connector

0.01-3GHz 3A High Current Bias Tee 50V RF DC Block 50ohms RF Coaxial Feed with N-Type Connector

$42.19

(0)

0.01-8GHz 50ohms DC Bias Tee RF Feedback High Current DC Block with SMA Female to Female Connector

Specification:
- Impedance: 50ohms
- Frequency response: 0.01 - 8GHz
- Insertion loss: 1.2dB (max)
- SWR: <1.3
- Maximum DC block voltage: 50V
- Maximum RF power: 2W
- Current: 2A (max)
- RF-DC isolation: ≥30dB
- Temperature range: -40℃ to 80℃
- Connector: SMA female to female connector

Package Included:
- 1 x Bias Tee
