100MHZ-8GHZ 15DB Digital Attenuator Module Step 1DB 4-Bit IC Chip HMC540

Availability: In stock, usually dispatched in 1 business day

  • Price:$29.81
  • Price in reward points: 298 Reward Points: 3
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $29.21 $28.62 $27.72 $26.53 Contact US
Quantity:

100MHZ-8GHZ 15DB Digital Attenuator Module Step 1DB 4-Bit IC Chip HMC540

Description:

The HMC540SLP3E is a broadband 4-bit IC chip digital attenuator in a low cost leadless surface mount package. This digital attenuator for each single positive voltage control line operates off-chip with an off-chip AC grounding capacitor, making it ideal for a wide range of RF and IF applications. Operating at 0.1 to 8 GHz, the insertion loss is less than 1 dB typical. The attenuator bit values are 1 (LSB), 2, 4, and 8 dB for a total attenuation of 15 dB. It has excellent attenuation accuracy with a typical step accuracy of ± 0.2 dB. The attenuator also has +56 dBm IP3. A four-bit TTL/CMOS control input is used to select each attenuation state. It can be powered by a single supply Vdd of +3.3V to 5V.

Application:

- Cellular Communications Infrastructure
- ISM, MMDS, WLAN, WiMAX, WiBro
- Microwave Radio and VSAT
- Test Equipment and Sensors

Package Included:
- 1 x Digital Attenuator
