Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
---|---|---|---|---|---|
Price /Unit | $52.42 | $51.35 | $49.75 | $47.61 | Contact US |
Description:
- Meet industrial requirements while achieving ultra-small size, which is convenient for outdoor use
- Support multiple devices, up to 16 channels can be connected at the
same time to send and receive at the same time, convenient for batch
testing & control
- Fully support CAN Classic 2.0B and CANFD protocol, up to 8000kbps data baud rate
- Innovative three-level frame buffer design, no frame loss in a 24-hour bus full load test in classic scenarios such as 500kbps
- Industry-leading host computer functions, supporting enterprise-level
functions such as DBC loading/recording playback/signal analysis/curve
drawing/node simulation/UDS/automatic testing
- Support loading UDS 27 security algorithm DLL to automatically unlock ECU (compatible with CANoe security DLL interface)
- Support secondary development, support Python-can/Linux/Raspberry Pi,
rich and practical example programs help you quickly customize
enterprise-level upper-level applications independently
- 2 hardware-level real-time receiving filters, exclusive support for message load content filtering
- 1 hardware-level timing sending task, self-increasing/random mode and other modes can be configured as you like
- Built-in 120Ω terminal resistance, to help you avoid complicated bus connections and reduce the failure rate
- Powerful automatic detection function of baud rate and terminal
resistance helps you avoid complicated software configuration and
improve work efficiency
- Computer USB interface over-current protection, strong protection of your computer safety
- Bus ESD protection to reduce bus failures caused by signal interference
- 2500V industrial electrical isolation
Exclusive support for 8000kbps baud rate
Support CAN-FD bit rate switching (BRS)
Support CAN-FD oversized 64-byte message load, 64 bytes*2500 packets/sec, message transmission and reception without frame loss
Before leaving the factory, each analyzer passes the CAN-FD arbitration
section 500kbps + data section 2000kbps classic car scene test
Customers who need to use ultra-high baud rates above 2000kbps, please note:
Please use high-quality low-capacitance twisted pair cables with a total length of no more than 1.5m
A 120 ohm terminal resistor is connected to each end of the twisted pair
Please keep good electromagnetic shielding for twisted pair
Please set the sampling point position of the CANFD analyzer reasonably (75% recommended)
Note:
The above test data source is imported PeakCAN-USB-Pro (support
CANFD) sent and generated in PcanView, the test conditions are close to
full load
The frame rate information of the above test comes from
the automatic receiving statistics function in the Network statistics in
the BusMaster enterprise-level host computer provided by this product
In the 64-byte long message mode, although the frame rate is less than
20000fps, the data throughput is as high as 486kB/s, which is larger
than the 8-byte short message!
