Assembled STM32 Smart Car Two Wheel Self Balanced Vehicle Robot 3 Layers APP Bluetooth Remote Control for Phones

Availability: In stock, usually dispatched in 1 business day

  • Price:$115.89
  • Price in reward points: 1159 Reward Points: 12
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $113.57 $111.25 $107.78 $103.14 Contact US
Quantity:

Assembled STM32 Smart Car Two Wheel Self Balanced Vehicle Robot 3 Layers APP Bluetooth Remote Control for Phones

Features:

- Integrates with bluetooth wireless module, Controlles by Android APP
- Motor: Original GB37-3530 super power motor
- Photoelectric encoder
- 3 layers for DIY, Max. load: up to 4kg
- Body height: 176mm, width:226mm
- Open source software

Specification:
- Power supply: LM2596S voltage-stabilizing IC
- Motor type: GB37-3530
- Tyre size: 68mm (outter dia.) 26.5mm (width)
- Car material: 4mm Acrylic organic glass
- Main control chip: STM32F 103C8T6
- Gyroscope: MPU6050
- Motor drive chip: TB6612FNG
- Bluetooth module: HC-06
- Ultrasonic module: HC-SR04
- Speed measurement: Photoelectric encoder448tvl grating
- Self-balancing life: >12h
- Max. balance load: 4kg( gravity<25cm); 2kg( gravity<40cm)
- Weight: 0.96kg
- Battery: 18650 lithium battery pack (not included)
- Charging: Free disassembly direct plug-in
- Smart charger: 12.6v 1000MA

Motor:
- Rated voltage: 12V
- Original speed: 10000RPM
- Non-load current: 120ma
- Max. locked rotor current : 1.2A
- Rated power: 4.8W
- Reduction ratio: 1:30
- Reduction box ratio: 22mm
- Blocked torque: 4.5kg.cm

Encoder:
- Type: AB phase photoelectric incremental encoder
- 448 TVL grating
- AB phase pulse output: 26880
- Power: 5V
- Interface: PH2.0-6P

Package included:
- 1 x Assembled STM32 Smart Car
- 1 x Smart charge
- 1 x Data CD
