DC-DC Buck Voltage Converter 36V 3A Adjustable Digital Step Down Voltage Regulator CC CV USB2.0 Port

Availability: In stock, usually dispatched in 1 business day

  • Price:$11.45
  • Price in reward points: 115 Reward Points: 1
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $11.22 $10.99 $10.65 $10.19 Contact US
Quantity:

DC-DC Buck Voltage Converter 36V 3A Adjustable Digital Step Down Voltage Regulator CC CV USB2.0 Port

Features:

- Adopted advanced microprocessor control, so you can adjust the voltage and current accurately by using the button, the voltage regulator has constant current & voltage output function
- DC-DC Digital Buck Voltage Regulator: input voltage DC 5-40V and output 0-36V/0-3A adjustable, high power, high efficiency and stable working
- Designed with 2 USB 2.0 charging ports, one for fixed voltage 5V, max output current is 1A; the other port is for 0-36V adjustable, max output current is 3A
- Can be set automatically output after powering on and you can lock the parameter regulating keys to avoid adjusting the output voltage and current by wrong operation
- 4-digit LED digital display so you can monitor the output voltage, current; Meanwhile, this digital step down module has LED indicators that you can monitor the working statues in real-time
- Dimension: 80.5 x 53.8 x 30 mm (L*W*H)

Parameters:

- Input Voltage Range: 5V-40V
- Output Voltage Adjustable Range: 0-36V
- Output Current Adjustable Range: 0-3A
- Output Power: 0-90W
- Output Voltage Setting Resolution: 10mV
- Output Current Setting Resolution: 1mA
- Power Supply Effect: CV <0.5%+10Mv, CC<1%+1mA
- Load Effect: CV<0.5%+10Mv, CC<1%+1mA
- Output Ripple: <40mVpp (input 30V, output 12V, current 1A)
- 100Hz Fluctuating Transmission Ratio: <1/10000
- Typical Efficiency: 85% (input 30V, output 12V, current 1A)
- Voltage, Current Display Accuracy: 10mV, 1mA
- Voltage Display Deviation: ±1%+20mV
- Current Display Deviation: ±2%+2mA
- Respond Time: <50ms
- Storage Operation: M0-M9, can storage total 10 groups of parameter
- Temperature of Operating Environment: 0-40℃
- Temperature of Storage Environment: -20-70℃
- Using Environment: Indoor, 80% maximum humidity
- Size: 80.5 x 53.8 x 30 mm (L*W*H)

Package Included:
- 1 x Buck Converter
