Eieye Mini Open-Source Camera Color Sensor Module Image Color Recognition Compatible w/Arduino

Availability: In stock, usually dispatched in 1 business day

  • Price:$74.13
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $0.00 $0.00 $0.00 $0.00 Contact US
Quantity:

Eieye Mini Open-Source Camera Color Sensor Module Image Color Recognition Compatible w/Arduino

Description:

Eieye is an image recognition sensor, supports multi objects, multi color recognition. You can tell it the color you want, and teach it to find something. Eieye supports a variety of communication methods, such as SPI, I2C etc., can dip in the Arduino control board. Put it on your robot. It equipped with the image sensor with a powerful hardware, you can coordinate with PC tracking, analysis of multi - color data.

The powerful processor is equipped with an image sensor, it will selectively deal with useful information, because it uses the color as the center of the method - to make this product is only the specific color of the visual data sent to the micro controller, rather than the output of all the visual data to carry out image processing.

Specifications:
- Processor: STM32F407, Cortex-M4, 168MHz
- Image sensor:  Omnivision OV7725 1/4", 640x480
- Target recognition resolution: 320x240
- Frame rate: 45fps
- Lens type: standard M12 , focal length 3.6mm
- Consumption current:  80~110mA
- Input current: USB input (5V) / wide voltage input (3.3V~5.5V)
- RAM: 168K bytes
- Flash:1M bytes
- Communication interface: UART serial, SPI, USB HS , I2C, digital
- Size: 4CM*4CM

Software:
- Source Open project: provide Keil project,, easy to twice development
- Algorithm: high recognition rate, rate 45fps, multi color target, up to 127 goals, allocation of 8 kinds of color recognition recognition, open source library provides, provides a single target identification code.
- Communication: support USB2.0 communication, UART, SPI, etc.
- Driver: DCMI, SPI, etc. are the DMA way, do not take up CPU resources
- Debugging tools: support JTAG, Eieye dedicated PC, PC to provide communication protocol

Package included:

- 1 x Eieye Mini Open-Source Camera
