  3. LILYGO T-Keyboard T-Deck ESP32-S3 Development Board w/ 2.8" Screen (H643-Mesh Black Keyboard 433MHz)
Por Thanksbuyer

LILYGO T-Keyboard T-Deck ESP32-S3 Development Board w/ 2.8" Screen (H643-Mesh Black Keyboard 433MHz)

$87.13
$87.13
Impuesto incluido. Los gastos de envío se calculan en la pantalla de pago.
Availability: 2000 en stock
SKU: 93521
Tags:
$87.13
$87.13
LILYGO T-Keyboard T-Deck ESP32-S3 Development Board w/ 2.8" Screen (H643-Mesh Black Keyboard 433MHz)

Details of T-Deck:
MCU: ESP32-S3FN16R8 Dual-core LX7 Microprocessor
* Wireless communication: 2.4GHz Wi-Fi & Bluetooth 5 (LE)
* Development environment: For Ar-duino, PlatformIO-IDE and Micropython
* Flash: 16MB; PSRAM: 8MB; Battery detection PIN: IO04
* Onboard functions: trackball, microphone, and speaker

2.8-Inch ST7789 SPI Interface IPS LCD
* Resolution: 320x240
* HD IPS color screen with full viewing angle

SX1262 LoRa Transceiver (Optional Chip)
* Transmit power: +22dBm
* Optional frequency: 433Mhz/868Mhz/915Mhz

Product Code:
Package Included (H643-Mesh):
* 1 x T-Deck
* 1 x Pin Header (6-pin)
* 1 x Battery Cable
* 1 x 433MHz FPC Antenna

Packaging Details:
* Weight: 0.5kg

Note:
* Battery is not included.
* Other items pictured below are not included, for demonstration purposes only. Thank you for your understanding!
